FreeFlight 2101 I/O Approach Plus GPS Navigation System
Notes:
1.
If a packet contains more than one of the same type of message string, the data from the
last message is used.
2.
The contents of the Error Log is to be determined.
3.
The Packet Checksum is the ASCII representation of the decimal value of the 8-bit,
unsigned sum of every byte in the packet excluding the ETX and the checksum message
string itself.
Page B-6
ITEM FORMAT
CONTENTS
ZAddd
Indicated Air Speed
ZBddd
True Air Speed
ZCddd
Mach Speed
ZDsdddd
Pressure Altitude
ZEsdddd
Density Altitude
ZFsdd
Outside Air Temperature s = sign, dd = celsius
ZGsdd
True Air Temperature
ZHddd
Wind Direction
ZIddd
Wind Speed
ZJsdd
Rate of Turn
ZKsddd
Vertical Speed
ZLddd
Heading
ZMdddd
Right Engine Fuel Flow
ZNddddd
Right Engine Fuel Used
ZOdddd
Left Engine Fuel Flow
ZPddddd
Left Engine Fuel Used
ZQddd
Error Log
ZRddd
Packet Checksum
DESCRIPTION
ddd =knots (5 to 385)
ddd = knots (40 to 600)
ddd = Mach x 1000 (0 to
999)
s = sign, dddd = tens of
feet (-100 to +5999)
s = sign, dddd = tens of
feet (-800 to +5999)
(-99 to +99)
s = sign, d = celsius (-99
to +99)
ddd = magnetic degrees
(0 to 359)
ddd = knots (0 to 150)
s = sign, dd =
degrees/second (-20 to
+20)
s = sign, ddd = tens of
feet/minute (-600 to
+600)
ddd = magnetic degrees
(0 to 359)
dddd = gal/hr (0 to
999.9)
dddd = gallons (0 to
9999.9)
dddd = gal/hr (0 to
999.9)
ddddd = gallons (0 to
9999.9)
ddd = number (0 to 255)
ddd = number (0 to 255)
Revision E
May 31, 2006
