FreeFlight 2101 I/O Approach Plus GPS Navigation System
PINOUT BY PIN NUMBER
PIN TYPE
J1-1 RS232/423
J1-2 RS422 IN
J1-3 GROUND
J1-4 RS423/232 OUT
J1-5 RS422 OUT
J1-6 RS232/423 OUT
J1-7 RS422 IN
J1-8 RS422 IN
J1-9 RS422 OUT
J1-10 RS232/423 OUT
J1-11 RESERVED
J1-12 OUT
J1-13 OUT
J1-14 OUT
J1-15 OUT
J1-16 IN
J1-17 IN
J1-18 RS422 IN
J1-19 RESERVED
J1-20 GROUND
J1-21 RESERVED
J1-22 RESERVED
J1-23 RS422 OUT
J1-24 RS422 IN
J1-25 OUT
J1-26 DISCRETE OUT
J1-27 RESERVED
J1-28 DISCRETE OUT
J1-29 RS422 OUT
J1-30 DISCRETE OUT
J1-31 OUT
J1-32 OUT
J1-33 OUT
J1-34 OUT
J1-35 RS422 OUT
J1-36 RS422 IN
J1-37 RS422 OUT
Page 2-6
SIGNAL
SERIAL COMMON
RXD3+
POWER GROUND
TXD3BP (BIPOLAR)
TXD1-
TXD1BP (BIPOLAR)
RXD1+
RXD1-
TXD2-
TXD2BP (BIPOLAR)
ONE PULSE PER SECOND
AUDIO (H)
MESSAGE ANNUNCIATOR
HOLD ANNUNCIATOR
POWER IN (+28 VDC)
POWER IN (+28 VDC)
RXD3-
POWER GROUND
TXD2+
RXD2+
CDI LOW LEVEL +NAV FLAG
NAV VALID (+28 VDC)
WAYPOINT ANNUNCIATOR
TXD3+
APPROACH ANNUNCIATOR
CDI LOW LEVEL COMMON
AUDIO (C)
CDI +RT/-LT
CDI +TO/-FROM
TXD3-
RXD2-
TXD1+
Figure 2-1 FreeFlight 2101 I/O Approach Plus J1 Pinout
NOTE
SEE APPENDIX B AND PAGE 2-25/26
SEE APPENDIX B
SEE APPENDIX B PAGE B-1
SEE APPENDIX B AND PAGE 2-27/28
SEE APPENDIX B AND PAGE 2-29
SEE APPENDIX B AND PAGE 2-25/26
SEE APPENDIX B AND PAGE 2-25/26
SEE APPENDIX B AND PAGE 2-27/28
SEE APPENDIX B AND PAGE 2-29
ACTIVE GND
ACTIVE GND
SEE APPENDIX B
SEE APPENDIX B AND PAGE 2-27/28
SEE APPENDIX B AND PAGE 2-25/26
J1-31 CDI LOW LEVEL COMMON
ACTIVE GND
SEE APPENDIX B
ACTIVE GND
J1-31 CDI LOW LEVEL COMMON
J1-31 CDI LOW LEVEL COMMON
SEE APPENDIX B
SEE APPENDIX B AND PAGE 2-25/26
SEE APPENDIX B AND PAGE 2-27/28
