FreeFlight 2101 I/O Approach Plus Installation And Checkout Manual page 106

FreeFlight 2101 I/O Approach Plus GPS Navigation System
INPUT
KIFIS A Synchro
KIFIS B Synchro
ARINC 419/429/575 DADS
Page C-2
CHARACTERISTICS
Source
Range
Resolution
Accuracy
Index Reference
Positive Direction Sense
Scale Factor
Reference Voltage
Loading
Reference pins
Synchro pins
Source
Range
Resolution
Accuracy
Index Reference
Positive Direction Sense
Scale Factor
Reference Voltage
Loading
Reference pins
Synchro pins
Port 1 pins
See Section C.1.4 for data format
DESCRIPTION
ARINC 407 three wire synchro
transmitter or equivalent
200 to 550 knots
1.0 knot
± 4 knots
366.66 knots is equal to
0° electrical
Increasing speed for
increasing angle
1.08°/knot
26 Vac ± 10%, 400 Hz ± 20 Hz
Reference: 10kΩ
Signal: 100kΩ
J2-18=H, J2-7=C (Ground)
J2-10=X, J2-12=Y, J2-14=Z
ARINC 407 three wire
transmitter or equivalent
200 to 550 knots
1.0 knot
± 4.0 knots
200 knots is equal to 72° electrical
Increasing speed for
increasing angle
72° electrical rotation/100 knots
26 Vac ± 10%, 400 Hz ± 20Hz
Reference: 10kΩ
Signal: 100kΩ
J2-18=H, J2-7=C (Ground)
J2-10=X, J2-12=Y, J2-14=Z
Digital Air Data
J2-9=RXA, J2-15=RXB
Revision E
May 31, 2006
