FreeFlight 2101 I/O Approach Plus GPS Navigation System
The following is an example of the flight plan information contained in the K0, K1, X0 and X1 formats.
The following is an example of the additional information contained only in the X0 and X1 formats.
kN 37 21.64728 W 121 55.16121 128.3
l 10312.4 ------- ------
m 137.42 138.4 R0.18 R0.31
n +0.0 ---- ---- ----
o 712.27314 138.942 5:34:15
p 13:52:17 -7.0
q R0.000
r 13:52:17.024
u 000.024
z G.GPS-3D:4 LOR:7
Page B-18
EXAMPLE
w01aAUS aaaaaaaa
Waypoint #1, AUS
w02bDFW bbbbbbbb
Waypoint #2, DFW
...
...
wnnxMCI xxxxxxxx
Last Waypoint, MCI
t aavavu...
Waypoint Types (one for every
waypoint in the flight plan)
EXAMPLE
DESCRIPTION
DESCRIPTION
Current Latitude N 37°21.64728'
GPS Altitude 10,312.4 feet
Magnetic Track 137.42°
Desired Track 138.4°
Cross-Track Error Right 0.18 nm
Track Angle Error Right 0.31°
No Vertical Navigation
Distance to waypoint 712.27314 nm
Bearing to waypint 138.942°
Time to waypoint 5h 34m 15s
Data time 13h 52m 17s
Offset from GMT to local time -7.0 hr
No Parallel Offset
Extended Time 13h 52m 17.024s
Extended Time since solution 0.024s
Sensor in Use GPS
GPS mode 3-D, 4 satellites
LORAN tracking 7 transmitters
Revision E
May 31, 2006
