FreeFlight 2101 I/O Approach Plus GPS Navigation System
1.3.3
GPS Antenna (P/N 16248-11) (alternate)
TSO COMPLIANCE
ENVIRONMENTAL COMPLIANCE
PHYSICAL DIMENSIONS
Height
Width
Length
WEIGHT
TEMPERATURE
ALTITUDE RANGE
MOUNTING
POWER REQUIREMENTS
SPEED RATING
CONNECTOR
* Installations utilizing this antenna are limited to aircraft not equipped with Satellite Communications equipment.
Page 1-6
C115a, C129 *
See Appendix A
0.80 in (2.0 cm)
3.75 in (9.53 cm)
4.00 in (10.16 cm)
0.5 lb (0.23 kg)
-55°C to +70°C
-1000 ft to +55,000 ft
External
+5 Vdc @ 80 mA from RDU
800 knots IAS
TNC
Revision E
May 31, 2006
