FreeFlight 2101 I/O Approach Plus GPS Navigation System
INPUT
Altitude Valid J2-11
Oleo J2-51
C.1.4

Digital Data Inputs

C.1.4.1 DADS
PORT 1 (J2- 9 and 15) – All software versions
PORT 3 (J2-61 and 62) – Software version 241C and later
LABEL
210
230
203
204
211
210
203
204
211
Note: Refer to Section C.2 to define format type (ARINC 419 or 429).
C.1.4.2 AHRS
PORT 2 (J2-60 and 59) – All software versions
PORT 4 (J2-64 and 63) – Software version 241C and later
LABEL
314
320
C.1.4.3 FUEL
PORT 1 (J2-9 and 15) – Software version 241C and later
PORT 3 (J2-61 and 62) – Software version 241C and later
PORT 4 (J2-64 and 63) – Software version 241B and earlier
LABEL
244
Page C-4
CHARACTERISTICS
Source
Status
Loading
Source
Status
Load
PARAMETER
TAS
TAS
Altitude (Press)
Altitude (Baro)
Total Air Temperature/Ram Air Temperature 419/575 BNR
OR
TAS
Altitude (Press)
Altitude (Baro)
Total Air Temperature/Ram Air Temperature 429 BNR
PARAMETER
Heading (True)
Heading (Mag)
PARAMETER
Fuel Flow Rate
DESCRIPTION
Aircraft Air Data System
+18.5 Vdc to +30 Vdc = Valid
0 to +3.5 Vdc = Not Valid
10kΩ minimum
Aircraft oleo strut switch
Programmable
10kΩ minimum
FORMAT INPUT
419/575 BNR 2W
419/575 BCD 2W
419/575 BNR 2W
419/575 BNR 2W
2W
429 BNR 2W
429 BNR 2W
429 BNR 2W
2W
FORMAT INPUT
429 BNR 2W
429 BNR 2W
FORMAT INPUT
429 BNR 2W
Revision E
May 31, 2006
