Page 1 FreeFlight FreeFlight 2101 I/O Approach Plus GPS Navigation System INSTALLATION AND CHECKOUT MANUAL Publication Number 82882...
Page 3 FreeFlight 2101 I/O Approach Plus GPS Navigation System INSTALLATION AND CHECKOUT MANUAL Publication Number 82882 Revision E, May 31, 2006...
Page 4 © 1997 - 2006 FREEFLIGHT SYSTEMS Reproduction of this publication or any portion thereof by any means without the express written permission of FREEFLIGHT SYSTEMS is prohibited. For further information contact, Manager, Technical Publications, FREEFLIGHT SYSTEMS, 3700 Interstate 35 S., Waco, Texas 76706-3756, USA. Telephone 1 (254) 662-...
Page 5: Table Of Contents
FreeFlight 2101 I/O Approach Plus GPS Navigation System Insert latest change pages and destroy superceded pages. LIST OF AFFECTED PAGES Dates of Original and Change pages are: Revision ..A ..February 28, 1997 Revision ..B ..July 14, 1997 Revision ..
Page 6 FreeFlight 2101 I/O Approach Plus GPS Navigation System RECORD OF REVISIONS Assigned To (Job Title) Location Revision Insertion Revision Insertion Date Date Date Date Revision E May 31, 2006 Page B...
Page 7: Table Of Contents
GPS Antenna (P/N 81194) ----------------------------------------------------------------------- 1-5 1.3.3 GPS Antenna (P/N 16248-11) (alternate) ---------------------------------------------------- 1-6 PARTS AND EQUIPMENT --------------------------------------------------------------------- 1-7 1.4.1 FreeFlight 2101 I/O Approach Plus GPS Receiver Display Unit ----------------------- 1-7 1.4.2 Installation Kit --------------------------------------------------------------------------------------- 1-7 ACCESSORIES NOT SUPPLIED ------------------------------------------------------------ 1-8 1.5.1 Installation -------------------------------------------------------------------------------------------- 1-8 1.5.2...
Page 8 FreeFlight 2101 I/O Plus Approach GPS Navigation System LIST OF FIGURES FreeFlight 2101 I/O Approach Plus J1 (37 Pin) Pin-out ---------------------------------- 2-6 FreeFlight 2101 I/O Approach Plus J2 (66 Pin) Pin-out ---------------------------------- 2-7 GPS Antenna Cable and Connector ---------------------------------------------------------- 2-9...
Page 9 FreeFlight 2101 I/O Approach Plus GPS Navigation System APPENDIX A - RTCA/DO-160 Environmental Qualification Forms RECEIVER/DISPLAY UNIT --------------------------------------------------------------------- A-1 GPS ANTENNA ------------------------------------------------------------------------------------ A-3 APPENDIX B - Serial Interface Specification INTRODUCTION ----------------------------------------------------------------------------------- B-1 BASIC COMMUNICATION PROTOCOL DESCRIPTIONS ------------------------------ B-1 B.2.1 RS-422 ----------------------------------------------------------------------------------------------- B-1 B.2.2...
Page 10 FreeFlight 2101 I/O Plus Approach GPS Navigation System THIS PAGE INTENTIONALLY LEFT BLANK Revision E Page iv May 31, 2006...
Page 11: Section I - General Information
FreeFlight 2101 I/O Approach Plus GPS Navigation System SECTION I GENERAL INFORMATION...
Page 13 GPS Antenna (P/N 81194) ----------------------------------------------------------------------- 1-5 1.3.3 GPS Antenna (P/N 16248-11) (alternate) ---------------------------------------------------- 1-6 PARTS AND EQUIPMENT --------------------------------------------------------------------- 1-7 1.4.1 FreeFlight 2101 I/O Approach GPS Receiver Display Unit ------------------------------ 1-7 1.4.2 Installation Kit --------------------------------------------------------------------------------------- 1-7 ACCESSORIES NOT SUPPLIED ------------------------------------------------------------ 1-8 1.5.1 Installation -------------------------------------------------------------------------------------------- 1-8 1.5.2...
Page 14 FreeFlight 2101 I/O Plus Approach GPS Navigation System THIS PAGE INTENTIONALLY LEFT BLANK Revision E Page 1-ii May 31, 2006...
Page 15: Introduction
The Jeppesen database cards provide up-to-date information about airports and other navigation aids around the world. The FreeFlight 2101 I/O Approach Plus GPS System comprises one Dzus-mounted Receiver/Display Unit (RDU) containing a GPS Receiver (12-channel), one GPS Antenna/ Preamp, and applicable installation hardware (see Section 1.4.2 for the appropriate part numbers).
Page 16: Receiver/Display Unit
FreeFlight 2101 I/O Approach Plus GPS Navigation System 1.2.1 Receiver/Display Unit The Receiver/Display Unit (RDU) is the main component of the FreeFlight 2101 I/O Approach Plus navigation system. The RDU consists of the GPS Receiver, the User Interface, and the System Interface. 1.2.1.1 GPS Receiver The GPS Receiver interprets the satellite transmissions to determine the current position.
Page 17: Gps Antenna
The GPS Antenna (P/N 81194) receives and amplifies GPS Signals. The GPS Antenna unit is an omnidirectional flat microstrip antenna with an integral preamplifier and is rated to 1300 knots IAS. An alternate antenna (P/N 16248-11) can be used with the FreeFlight 2101 I/O APPROACH Plus in installations without Satcom. Antenna P/N 81194 is recommended.
Page 18: Technical Characteristics
FreeFlight 2101 I/O Approach Plus GPS Navigation System TECHNICAL CHARACTERISTICS 1.3.1 Receiver/Display Units (P/N 81440-XX) ENVIRONMENTAL COMPLIANCE See Appendix A TSO COMPLIANCE C129 (A1) PHYSICAL DIMENSIONS Height 3.0 in (7.62 cm) Width 5.70 in (14.48 cm) Depth 7.68 in (19.50 cm) WEIGHT 3.25 lbs (1.48 kg)
Page 19: Gps Antenna (P/N 81194)
FreeFlight 2101 I/O Approach Plus GPS Navigation System 1.3.1.1 GPS Receiver TYPE L1 Frequency (1575 MHz), C/A Code, Twelve Channel ACQUISITION TIME 1.5 to 3.5 minutes POSITION UPDATE RATE 5 per second DYNAMICS 800 knots, 6g (tracking) ACCURACY Position 15 meters RMS** Velocity 0.1 knots steady state**...
Page 20: Gps Antenna (P/N 16248-11) (Alternate)
FreeFlight 2101 I/O Approach Plus GPS Navigation System 1.3.3 GPS Antenna (P/N 16248-11) (alternate) TSO COMPLIANCE C115a, C129 * ENVIRONMENTAL COMPLIANCE See Appendix A PHYSICAL DIMENSIONS Height 0.80 in (2.0 cm) Width 3.75 in (9.53 cm) Length 4.00 in (10.16 cm) WEIGHT 0.5 lb (0.23 kg)
Page 21: Parts And Equipment
The Installation Kit contains decals, labels, NavData subscription form, manuals, appropriate connectors, and installation hardware. This is provided as a convenience to the installation agency and FreeFlight reserves the right to substitute equivalent parts without prior notice. The contents are listed below:...
Page 22: Accessories Not Supplied
Current certification guidelines (AC 20-138A) require an altitude input for A1 and A2 certification. The FreeFlight 2101 I/O Approach Plus accepts a serial altitude input in addition to DADS and Synchro formats. Additional equipment may be necessary to provide this serial altitude input.
Page 23 FreeFlight 2101 I/O Approach Plus GPS Navigation System The following parts (for use with RG-393 cable) are available from FreeFlight: DESCRIPTION VENDOR One or two of the following: 26479-0495 TNC straight 1 or 2 1-225550-3 26479-0494 Connector, RF, TNC, 90°...
Page 24 FreeFlight 2101 I/O Approach Plus GPS Navigation System THIS PAGE INTENTIONALLY LEFT BLANK Revision E Page 1-10 May 31, 2006...
Page 25: Section Ii - Installation
FreeFlight 2101 I/O Approach Plus GPS Navigation System SECTION II INSTALLATION...
Page 27 2.3.4 Receiver/Display Unit Installation -------------------------------------------------------------- 2-4 LIST OF FIGURES FreeFlight 2101 I/O Approach Plus J1 (37 Pin) Pin-out ---------------------------------- 2-6 FreeFlight 2101 I/O Approach Plus J2 (66 Pin) Pin-out ---------------------------------- 2-7 GPS Antenna Cable and Connector ---------------------------------------------------------- 2-9 ARINC 743 Hi Speed GPS Antenna (P/N 81194) Installation Drawing ------------- 2-11...
Page 28 FreeFlight 2101 I/O Plus Approach GPS Navigation System THIS PAGE INTENTIONALLY LEFT BLANK Revision E Page 2-ii May 31, 2006...
Page 29: General
SECTION II - Installation GENERAL This section provides general information for installing the FreeFlight 2101 I/O Approach Plus GPS Navigation System. The cables will be fabricated by the installation agency to fit these various requirements. This section contains interconnect diagrams, mounting dimensions and information pertaining to installation.
Page 30: Gps Antenna Installation
The GPS antenna, the antenna gasket (-21kit only) and two 90° TNC connectors are provided in the installation kit. Straight TNC connectors are also available from FreeFlight. Proper antenna installation is critical to both the performance of the system and the aircraft's structural integrity.
Page 31 FreeFlight 2101 I/O Approach Plus GPS Navigation System • Fastening to Fuselage (for 16248-11 antenna) CAUTION Do not tighten screws with more than 20 inch-pounds of torque. Damage to antenna will result and void warranty. Torque value = 18 ±2 inch-pounds.
Page 32: Receiver/Display Unit Installation
FreeFlight 2101 I/O Approach Plus GPS Navigation System 2.3.4 Receiver/Display Unit Installation 2.3.4.1 Unit Installation Select a mounting location that will allow easy viewing of the unit's display during normal instrument panel scan and allow easy access to the front panel controls. After the desired mounting location is identified, refer to Figure 2-6 for unit outline and mounting dimensions.
Page 33 FreeFlight 2101 I/O Approach Plus GPS Navigation System 2.3.4.4 J2 Wiring Notes The external wire supplied by the installing agency should be MIL-W-16878E/4 or equivalent, 22 gauge with the exception of the digital data connections (pins 9, 15, 16, 23, and 57 - 64). Digital data connections require 22 gauge twisted shielded pairs.
Page 34 TXD3- SEE APPENDIX B J1-36 RS422 IN RXD2- SEE APPENDIX B AND PAGE 2-25/26 J1-37 RS422 OUT TXD1+ SEE APPENDIX B AND PAGE 2-27/28 Figure 2-1 FreeFlight 2101 I/O Approach Plus J1 Pinout Revision E May 31, 2006 Page 2-6...
Page 35 DISCRETE OUT ROLL STEERING VALID (+28 VDC) J2-49 ARINC 561/568 OUT 6W SYNC (H) USE J1-26 FOR VALID IF REQUIRED Reserved for future use. Figure 2-2 FreeFlight 2101 I/O Approach Plus J2 Pin-out Revision E May 31, 2006 Page 2-7...
Page 36 ARINC 419/429 IN RX4A SEE TABLES 3-2 AND 3-3 J2-65 POWER IN + 28 VDC J2-66 POWER IN + 28 VDC Reserved for future use. Figure 2-2 FreeFlight 2101 I/O Approach Plus J2 Pin-out (continued) Revision E May 31, 2006 Page 2-8...
Page 37: Gps Antenna Cable And Connector
FreeFlight 2101 I/O Approach Plus GPS Navigation System 0.5 ± .010 0.187 ± .010 GPS ANTENNA CABLE TERMINATION P/N 26479-0494 Figure 2-3 GPS Antenna Cable and Connector Revision E May 31, 2006 Page 2-9...
Page 38 FreeFlight 2101 I/O Approach Plus GPS Navigation System This Page Intentionally Left Blank Revision E May 31, 2006 Page 2-10...
Page 39: Arinc 743 Hi Speed Gps Antenna (P/N 81194) Installation Drawing
FreeFlight 2101 I/O Approach GPS Navigation System Figure 2-4 ARINC 743 Hi Speed GPS Antenna (P/N 81194) Installation Drawing Revision E May 31, 2006 Page 2-11/12...
Page 40: Gps Antenna (P/N 16248-11) Installation Drawing (Alternate)
FreeFlight 2101 I/O Approach GPS Navigation System Notes: Installations utilizing this antenna are limited to aircraft not equipped with Satellite Communications equipment. Recommended mounting screws are 8-32 UNF stainless steel (4 pl.) Figure 2-5 GPS Antenna (P/N 16248-11) Installation Drawing (alternate)
Page 41: Freeflight 2101 I/O Approach Plus Installation Drawing
The isometric view in this drawing illustrates the assembly of an Air Duct attachment kit P/N 81515-00 for forced air cooling and can be purchased from FreeFlight. Figure 2-6 FreeFlight 2101 I/O Approach Plus Installation Drawing Revision E May 31, 2006...
Page 42: System Inputs
FreeFlight 2101 I/O Approach Plus GPS Navigation System Figure 2-7 System Inputs Revision E May 31, 2006 Page 2-17...
Page 43 FreeFlight 2101 I/O Approach Plus GPS Navigation System Figure 2-8 System Outputs Revision E May 31, 2006 Page 2-18...
Page 44: Oleo Inputs
FreeFlight 2101 I/O Approach Plus GPS Navigation System Notes: Collective in detent or low rotor RPM switches may be used in place of oleo switch when system is installed in helicopters. Refer to OLEO logic programming under AUX INSTALL in the Pilot Guide.
Page 45: Cdi/Hsi Interconnection
FreeFlight 2101 I/O Approach Plus GPS Navigation System FreeFlight BENDIX OUTPUT 2101 I/O BENDIX BENDIX BENDIX COLLINS TERRA KING CENTURY SIGMA-TEK COLLINS MID-CONT NAME Approach KING KING KING IND 350A TRI-NAV C KI 525a NSD 360a IU 445 PN 101...
Page 46: Typical System Interconnection
FreeFlight 2101 I/O Approach Plus GPS Navigation System TAS Type (See Note 1) Serial Shadin ADC-200 Digital Digital 429 DADS 565 AC hi Voltage Ratio ARINC 565 AC, high speed 565 AC lo Voltage Ratio ARINC 565 AC, low speed...
Page 47 FreeFlight 2101 I/O Approach Plus GPS Navigation System Figure 2-11 Typical System Interconnection (sheet 2 of 3) Revision E May 31, 2006 Page 2-23/24...
Page 48 FreeFlight 2101 I/O Approach Plus GPS Navigation System Figure 2-11 Typical System Interconnection (sheet 3 of 3) Revision E May 31, 2006 Page 2-25/26...
Page 49: Serial Port Input Connections
J1-3,20 SHIELD SETUP ENCODER ENCODER ENCODER ENCODER ENCODER ENCODER FreeFlight P/N 12480-00 - RS-232 Adapter Input Connections for use with Port 1 and Port 2 Notes: FreeFlight 2101 FreeFlight 2101 RS-422/232 ADAPTER PC SERIAL PC SERIAL SIGNAL I/O Approach I/O Approach...
Page 50: Serial Port Output Connections
J1-5 J1-9 CABLE J1-3,20 J1-3,20 SHIELD SETUP K0 OR ARGUS FreeFlight P/N 12480-00 - RS-422/232 Adapter Output Connections for use with Port 1 and Port 2 FreeFlight 2101 FreeFlight 2101 RS-422/232 ADAPTER ARTEX PC SERIAL PC SERIAL SIGNAL I/O Approach...
Page 51: Bipolar Serial Port Interconnections
FreeFlight 2101 I/O Approach Plus GPS Navigation System FreeFlight FreeFlight PC SERIAL PC SERIAL SIGNAL 2101 I/O 2101 I/O ARTEX PORT PORT NAME Approach Plus Approach Plus ELS 10 (25 PIN D) (9 PIN D) BP PORT 1 BP PORT 2...
Page 52 FreeFlight 2101 I/O Approach Plus GPS Navigation System THIS PAGE INTENTIONALLY LEFT BLANK Revision E May 31, 2006 Page 2-32...
Page 53: Section Iii - Checkout
FreeFlight 2101 I/O Approach Plus GPS Navigation System SECTION III CHECKOUT...
Page 55 FreeFlight 2101 I/O Approach GPS Navigation System TABLE OF CONTENTS SECTION III - Checkout GENERAL ------------------------------------------------------------------------------------------ 3-1 3.1.1 Continued Airworthiness Requirements ------------------------------------------------------ 3-1 SYSTEM CHECKOUT --------------------------------------------------------------------------- 3-1 3.2.1 Preliminary Test ------------------------------------------------------------------------------------ 3-1 3.2.2 Installation Setup ----------------------------------------------------------------------------------- 3-1 3.2.3 I/O Interface Check ------------------------------------------------------------------------------ 3-12 3.2.4...
Page 56 FreeFlight 2101 I/O Approach GPS Navigation System THIS PAGE INTENTIONALLY LEFT BLANK Revision E Page 3-ii May 31, 2006...
Page 57: General
The FreeFlight 2101 I/O Approach Plus requires no periodic maintenance or calibration. Maintenance is performed on an on-condition basis only. The FreeFlight 2101 I/O Approach Plus is continually tested using Built-In Test Equipment (BITE) when the system is in operation. This method of testing will notify the operator of a failure. System software updates are accomplished using the card slot on the front of the unit and instructions described in normal Service Bulletin notification.
Page 58 FreeFlight 2101 I/O Approach Plus GPS Navigation System Installation Setup is accessible by following these steps: Press the key until the CONFIGURE submode is activated. Rotate the small knob until DISPLAY DIAGNOSTIC is displayed. Enter the following key sequence: Press and use the small knob to select ENABLE.
Page 59: Aux I/O Configuration
FreeFlight 2101 I/O Approach Plus GPS Navigation System I/O Category Choices TAS INPUT None* Serial - from ADC via RS-422/RS-232 Digital - from DADS via ARINC 419/429/Hi/Lo Port 1 565 AC High Speed 565 AC Low Speed 565 DC 545 - Synchro...
Page 60 FreeFlight 2101 I/O Approach Plus GPS Navigation System Notes: Each of the three FreeFlight 2101 I/O Approach Plus synchros may be programmed to output one of the angles listed below, in either SYNCHRO or SIN/COS format, and either offset by 180° or not:...
Page 61: Arinc 419/429 Receiver Port Options (241B And Earlier Software Versions)
FreeFlight 2101 I/O Approach Plus GPS Navigation System 3.2.2.2.1 Digital Input Data Setup Data type and speed for each port can be selected during installation setup. An example of the Digital Data setup page is shown below. See Table 3-2 for Receiver Port Options for software version 241B and earlier. See Table 3-3 for Receiver Port Options for software versions 241C and later.
Page 62: Arinc 419/429 Receiver Port Options (241C And Later Software Versions)
FreeFlight 2101 I/O Approach Plus GPS Navigation System ARINC Format Port 1 Port 2 Port 3 Port 4 J2 – 9 and 15 J2 – 60 and 59 J2 – 61 and 62 J2 – 64 and 63 419 DADS...
Page 63 FreeFlight 2101 I/O Approach Plus GPS Navigation System 3.2.2.3 Set Audio Level Set the Audio Level and Frequency by accessing the Installation Setup and following these steps: Rotate the small knob to display SET AUDIO LEVEL. Press Rotate the small knob. The Navigator will cause a test beep on an external speaker. Continue rotating the knob until the audio is set to the desired level.
Page 64: User Units
FreeFlight 2101 I/O Approach Plus GPS Navigation System 3.2.2.5 Set User Units Access the Installation Setup and rotate the small inner knob to select User Units, then turn the large outer knob to sequence through each of the User Units categories listed in Table 3-4. At each category, press then use the small selector knob to scroll through the choices.
Page 65: Approach Message Options
FreeFlight 2101 I/O Approach Plus GPS Navigation System 3.2.2.6 Set Advisory Messages Most message displays can be configured to one of the following settings: Disables display of the message Enables display of the message when appropriate, but keeps messages in the queue until selected by the user for display Pop-Up Enables display of the message automatically when appropriate.
Page 66: Advisory Message Options
FreeFlight 2101 I/O Approach Plus GPS Navigation System Message Description Available Settings Default Setting √ √ √ Flight Plan Turn Displays next Leg Course and time to Countdown next Turn Point in Flight Plan (Auto set to "OFF" when Approach Profile is Active) √...
Page 67 FreeFlight 2101 I/O Approach Plus GPS Navigation System 3.2.2.7 Set GPS Antenna Height The GPS antenna height above a reference point must be specified to correctly calculate GPS altitude. When GPS altitude is displayed, the value will have been reduced by the antenna height offset.
Page 68: I/O Interface Check
FreeFlight 2101 I/O Approach Plus GPS Navigation System 3.2.2.11 Set Magnetic Variation Magnetic Variation can be set a any value between 180º West and 180º East. The factory default setting is AUTO. To change the magnetic variation, access the Installation Setup and follow these steps:...
Page 69 FreeFlight 2101 I/O Approach Plus GPS Navigation System 3.2.3.2 Output Verification After the CDI deflection test has been completed, press to display "FLAG: FROM" on the top line, indicating the CDI's FROM flag should be in view. Refer to the display below.
Page 70: Gps Receiver Tests
A flashing satellite number indicates a satellite which is being tracked but not being used in the position solution. The GPS annunciator on the FreeFlight 2101 I/O Approach Plus front panel indicates that sufficient satellites are being used to provide position updates.
Page 71 If the number of satellites in use drops to the point that GPS navigation is no longer possible, then too much interference exists between VHF radio and the FreeFlight 2101 I/O Approach Plus. Two common sources of interference are from the VHF radio front panel to the GPS antenna and from the VHF antenna to the GPS antenna.
Page 72: Final
FreeFlight 2101 I/O Approach Plus GPS Navigation System 3.2.4.4 GPS Position Update To conduct the GPS Position Update test, press until the SYSTEM STATUS submode is selected. Turn the small knob to display the present position. If the displayed position is more than 1000 miles from the actual position, press .
Page 73: Configuration Record Sheet
FreeFlight 2101 I/O Approach Plus GPS Navigation System Configuration Record Sheet (Keep with Installation Manual) Plane Make and Model ______________________________________________ Owner ________________________________________________________ Address ________________________________________________________ ________________________________________________________ ________________________________________________________ Unit Installed ______________________________________________________ Serial Number _____________________________________________________ Installation Agency _________________________________________________ Address ________________________________________________________ ________________________________________________________ ________________________________________________________ Serial Port Configuration...
Page 74: User Units
FreeFlight 2101 I/O Approach Plus GPS Navigation System Installation Setup FEATURE SETTING Audio Level CDI Sensitivity - Internal CDI Sensitivity - External User Units Position Display 1 Position Display 2 Position Datum Distance Display Units Speed Display Units Altitude Display Units...
Page 75 FreeFlight 2101 I/O Approach Plus GPS Navigation System Configuration Record Sheet (Pilot Guide Copy) Plane Make and Model ______________________________________________ Owner ________________________________________________________ Address ________________________________________________________ ________________________________________________________ ________________________________________________________ Unit Installed ______________________________________________________ Serial Number _____________________________________________________ Installation Agency _________________________________________________ Address ________________________________________________________ ________________________________________________________ ________________________________________________________ Serial Port Configuration...
Page 76 FreeFlight 2101 I/O Approach Plus GPS Navigation System Installation Setup FEATURE SETTING Audio Level CDI Sensitivity - Internal CDI Sensitivity - External User Units Position Display 1 Position Display 2 Position Datum Distance Display Units Speed Display Units Altitude Display Units...
Page 77 FreeFlight 2101 I/O Approach Plus GPS Navigation System APPENDIX A RTCA/DO-160 ENVIRONMENTAL QUALIFICATION FORMS...
Page 79: Appendix A - Rtca/Do-160 Environmental Qualification Forms
FreeFlight 2101 I/O Approach Plus GPS Receiver APPENDIX A - RTCA/DO-160 Environmental Qualification Forms RECEIVER/DISPLAY UNIT RTCA/DO-160C ENVIRONMENTAL QUALIFICATION FORM Nomenclature FreeFlight 2101 I/O Approach Plus GPS Receiver Unit Part Number 81440-02, -03, -12 TSO Number C129 (A1) Manufacturer FreeFlight Systems Address 3700 Interstate 35 S.
Page 80 FreeFlight 2101 I/O Approach Plus GPS Receiver RTCA/DO-160E ENVIRONMENTAL QUALIFICATION FORM Nomenclature FreeFlight 2101 I/O Approach Plus GPS Receiver Unit Part Number 81440-32, -33, -42 TSO Number C129 (A1) Manufacturer FreeFlight Systems Address 3700 Interstate 35 S. Waco, TX 76706-3756...
Page 81 FreeFlight 2101 I/O Approach Plus GPS Receiver GPS ANTENNA RTCA/DO-160C / 160D ENVIRONMENTAL QUALIFICATION FORM Nomenclature ARINC 743 Hi Speed GPS Antenna Part Number 81194 TSO Number C129, C144 Manufacturer Sensor Systems Aeroantenna Technology, Inc. Address 8929 Fullbright Ave. 20732 Lassen St.
Page 82 FreeFlight 2101 I/O Approach Plus GPS Receiver RTCA/DO-160C ENVIRONMENTAL QUALIFICATION FORM Nomenclature GPS Antenna/Preamp Part Number 16248-11 TSO Number C115a, C129 Manufacturer FreeFlight Systems Address 3700 Interstate 35 S. Waco, TX 76706-3756 CONDITIONS PARA CONDUCTED TESTS Temperature Category F2 Altitude...
Page 83 FreeFlight 2101 I/O Approach Plus GPS Navigation System APPENDIX B SERIAL INTERFACE SPECIFICATION...
Page 85: Basic Communication Protocol Descriptions
APPENDIX B - Serial Interface Specification INTRODUCTION Serial communication capabilities for the FreeFlight 2101 I/O Approach Plus are provided by two bi-directional serial communication ports compatible with EIA RS-232 and RS-422 protocols. Different formats may be selected on each port providing the user flexibility in interfacing various systems with the FreeFlight 2101 I/O Approach Plus.
Page 86: Connector Pin Assignments
FreeFlight 2101 I/O Approach Plus GPS Navigation System CONNECTOR PIN ASSIGNMENTS All interface connections are provided on a 37-pin connector. The following table defines pin numbers, functions, and descriptions for all serial interface pins utilized on the FreeFlight 2101 I/O Approach Plus. FUNCTION DESCRIPTION...
Page 87: Software Configuration Of Serial Ports
SERIAL-1 out • SERIAL-2 in • SERIAL-2 out To configure the serial ports of the FreeFlight 2101 I/O APPROACH PLUS, perform the following steps: • Press until the INSTALL submode is activated • Rotate the small, inner selector knob until the unit displays SERIAL-1 or SERIAL-2 in the top line •...
Page 88: Rmi Data Format
FreeFlight 2101 I/O Approach Plus GPS Navigation System B.5.3 RMI Data Format The Rocky Mountain Instruments µEncoder Airdata System transmits a 61-byte ASCII data frame once per second. The RMI configuration consists of the following parameters: Baud: 1200 Parity: None...
Page 89: Air Data Computer Format
FreeFlight 2101 I/O Approach Plus GPS Navigation System BYTE #1 BYTE #2 BYTE #3 BYTE #4 NUMBER FT/ALT CONV FLAP In Hg GEAR decimal pt HOLD UPATI DOWNATI temp - sign MACH In Hg decimal pt Indicator Byte Table B.5.4...
Page 90 FreeFlight 2101 I/O Approach Plus GPS Navigation System ITEM FORMAT CONTENTS DESCRIPTION ZAddd Indicated Air Speed ddd =knots (5 to 385) ZBddd True Air Speed ddd = knots (40 to 600) ZCddd Mach Speed ddd = Mach x 1000 (0 to...
Page 91: Transmit Ports
FreeFlight 2101 I/O Approach Plus GPS Navigation System TRANSMIT PORTS B.6.1 Configuration Transmit Ports 1 and 2 (TXD1 and TXD2) provide interface capability with a variety of peripheral devices such as moving maps and fuel flow computers, as well as providing data to users for custom applications. Adapters are available for each port to provide RS-422 and/or RS-232 signals.
Page 92 FreeFlight 2101 I/O Approach Plus GPS Navigation System The following information is output: INFORMATION OUTPUT Latitude (LAT) North or South degrees Longitude (LON) East or West degrees Track (TK) Magnetic degrees Ground Speed (GS) Knots Distance to Destination Waypoint (DIS)
Page 93 FreeFlight 2101 I/O Approach Plus GPS Navigation System The following table describes the contents of the R0 and the R1 data formats: ITEM FIELD ITEM FORMAT ITEM DESCRIPTION DESIGNATOR WIDTH N dd mmmm LAT (N or S, deg, min x 100)
Page 94: K0 And K1 Data Formats
FreeFlight 2101 I/O Approach Plus GPS Navigation System B.6.3 K0 and K1 Data Formats The K0 and the K1 formats present all the R0 and R1 information explained in the last section. In addition, the K0 and K1 formats add flight plan information. Each waypoint is sent as a separate line terminated with a CR (for K0) and a CR, LF (for K1).
Page 95 FreeFlight 2101 I/O Approach Plus GPS Navigation System Bytes 7 through 13 -- Latitude/Longitude Latitude and longitude of waypoint. Packed, unsigned binary values for degrees, minutes and hundredths of minutes. BYTE CONTENT Where: 0 if North latitude 1 if South latitude...
Page 96 FreeFlight 2101 I/O Approach Plus GPS Navigation System Where: BYTE CONTENT nnnnnnnn Magnetic variation at waypoint. Two’s complement binary in sixteenths of degrees. Easterly variation is positive. Note: A value of 7FH in byte 14 indicates that magnetic variation is not presently available and bytes 14 and 15 should be ignored.
Page 97: X0 And X1 Formats
Leading zeros and a space between the item designator are optional and may not appear on some items. All fields are in ASCII. Any item designator not specified is reserved for FreeFlight use. The following data is output:...
Page 98 FreeFlight 2101 I/O Approach Plus GPS Navigation System Position and Speed ITEM INFORMATION ITEM FORMAT DESIGNATOR Position and Speed a bb cc.cccc d eee ff.ffff ggg.g Where: a bb cc.cccc Current Latitude N or S (a), degrees (bb), minutes (cc.cccc) d eee ff.ffff...
Page 99 FreeFlight 2101 I/O Approach Plus GPS Navigation System Distance/Bearing/Time to Waypoint ITEM INFORMATION ITEM FORMAT DESIGNATOR Bearing, Distance, and Time to aaaa.aaaaa bbb.bbb cc:dd:ee Waypoint Where: aaaa.aaaaa Distance to Waypoint in nm bbb.bbb Bearing to Waypoint in degrees cc:dd:ee Time to Waypoint in hours (cc), minutes (dd), and seconds (ee)
Page 100 LORAN Mode, number of transmitters used in fix (d), integer number. Note: Other FreeFlight proprietary sentences beginning with an asterisk (*) may appear. These are for FreeFlight test equipment. They may change or disappear without notice. These labels are intended for FreeFlight internal use only.
Page 101: Data Output Format Example
FreeFlight 2101 I/O Approach Plus GPS Navigation System B.6.5 Data Output Format Example The following is an example of the data output for the R0 and R1 formats. It is also the first part of the K0, K1, X0, and X1 formats.
Page 102 FreeFlight 2101 I/O Approach Plus GPS Navigation System The following is an example of the flight plan information contained in the K0, K1, X0 and X1 formats. EXAMPLE DESCRIPTION w01aAUS aaaaaaaa Waypoint #1, AUS w02bDFW bbbbbbbb Waypoint #2, DFW wnnxMCI xxxxxxxx Last Waypoint, MCI t aavavu...
Page 103: External Inputs
FreeFlight 2101 I/O Approach Plus GPS Navigation System APPENDIX C EXTERNAL INPUTS AND OUTPUTS...
Page 105: Speed Inputs
FreeFlight 2101 I/O Approach Plus GPS Navigation System APPENDIX C - External Inputs and Outputs EXTERNAL INPUTS C.1.1 Speed Inputs Input Characteristics Description ARINC 545 Synchro Source ARINC 407 three wire synchro transmitter or equivalent Range 100 to 650 knots Resolution 1.0 knot...
Page 106 FreeFlight 2101 I/O Approach Plus GPS Navigation System INPUT CHARACTERISTICS DESCRIPTION KIFIS A Synchro Source ARINC 407 three wire synchro transmitter or equivalent Range 200 to 550 knots Resolution 1.0 knot Accuracy ± 4 knots Index Reference 366.66 knots is equal to 0°...
Page 107: Heading Input
FreeFlight 2101 I/O Approach Plus GPS Navigation System INPUT CHARACTERISTICS DESCRIPTION ARINC 565 dc Analog Source dc amplified, or equivalent, Voltage Ratio having low side ground inside (Output #4) sending unit Range 0 to 599 knots Resolution 4 knots Accuracy ±...
Page 108: Digital Data Inputs
FreeFlight 2101 I/O Approach Plus GPS Navigation System INPUT CHARACTERISTICS DESCRIPTION Altitude Valid J2-11 Source Aircraft Air Data System Status +18.5 Vdc to +30 Vdc = Valid 0 to +3.5 Vdc = Not Valid Loading 10kΩ minimum Oleo J2-51 Source...
Page 109 FreeFlight 2101 I/O Approach Plus GPS Navigation System C.1.4.4 GNS (Reserved for use with Honeywell Satellite Landing System) PORT 1 (J2-9 and 15) – Software version 241C and later PORT 3 (J2-61 and 62) –Software version 241C and later LABEL...
Page 110: System Outputs
FreeFlight 2101 I/O Approach Plus GPS Navigation System SYSTEM OUTPUTS C.2.1 Lateral Deviation (DC Crosstrack) (LT/RT) OUTPUT CHARACTERISTICS DESCRIPTION Low Level (J1-33) Source Analog voltage source referenced to ground 0 to ±150 µA into 1000Ω load Range 1.17 µA Resolution 10 µA centering...
Page 111: Glideslope Flag
FreeFlight 2101 I/O Approach Plus GPS Navigation System C.2.4 Steering OUTPUT CHARACTERISTICS DESCRIPTION Steering (J2-46) Source AC analog voltage generator utilizing external reference voltage Range 0° to ± 30° Roll Steering Command Resolution 0.1° of Roll command Accuracy 0.3° of Roll command...
Page 112 FreeFlight 2101 I/O Approach Plus GPS Navigation System C.2.7 Discretes OUTPUT CHARACTERISTICS DESCRIPTION Leg Change (J2-28) Source Transistor current sink Status 0 to 1 Vdc = leg change Open otherwise Load Capability 200 mA current sink Steering Valid (J2-48) Source...
Page 113: Hsi #1, 2, And 3 Synchros
FreeFlight 2101 I/O Approach Plus GPS Navigation System C.2.8 HSI #1, 2, and 3 Synchros Note: Each of the three synchros may be programmed to output one of the angles listed below, in either ARINC 407 Synchro or Sin/Cos format, and either offset by 180° or not.
Page 114: Digital Data Bus
FreeFlight 2101 I/O Approach Plus GPS Navigation System C.2.9 Digital Data Bus C.2.9.1 ARINC 419 Output Parameters PORT 1 (J2-16 and 23) – Selectable on all software versions PORT 2 (J2-58 and 57) – Selectable on software version 241C and later NOTE: The following ARINC 419 labels are transmitted for ARINC 419 selection.
Page 115 FreeFlight 2101 I/O Approach Plus GPS Navigation System C.2.9.2 ARINC 429 Output Parameters PORT 1 (J2-16 and 23) – Selectable on software version 241C and later PORT 2 (J2-58 and 57) – Selectable on all software versions NOTE: The following ARINC 429 labels are transmitted for ARINC 429 LO, ARINC 429 HI, ARINC 429 GAMA LO, ARINC 429 GAMA HI, and ARINC 429 VDL LO¹...
Page 116 FreeFlight 2101 I/O Approach Plus GPS Navigation System C.2.9.3 ARINC 429 Non-GAMA Output Parameters PORT 1 (J2-16 and 23) – Software version 241C and later PORT 2 (J2-58 and 57) – All software versions NOTE: The following ARINC 429 Non-GAMA labels are transmitted for ARINC 429 LO, ARINC 429 HI, and ARINC 429 VDL LO* selections.
Page 117 FreeFlight 2101 I/O Approach Plus GPS Navigation System C.2.9.4 ARINC 429 GAMA Output Parameters PORT 1 (J2-16 and 23) – Software version 241C and later PORT 2 (J2-58 and 57) – All software versions NOTE: The following ARINC 429 GAMA labels are transmitted only for ARINC 429 GAMA LO and ARINC 429 GAMA HI selections.
Page 118 FreeFlight 2101 I/O Approach Plus GPS Navigation System C.2.9.6 ARINC 561 Output Parameters PORT 3 - (J2-32, 47, and 49) LABEL PARAMETER FORMAT OUTPUT RATE Distance 419 BCD 200 ms 419 BCD 200 ms Crosstrack 419 BCD 200 ms Desired Track (True)
Page 119 FreeFlight 2101 I/O Approach Plus GPS Navigation System C.2.9.8 ARINC 743 TAWS Output Parameters PORT 1 (J2-16 and 23) – Software version 241F and later PORT 2 (J2-58 and 57) – Software version 241F and later LABEL PARAMETER FORMAT OUTPUT RATE...
Page 120 FreeFlight 2101 I/O Approach Plus GPS Navigation System THIS PAGE INTENTIONALLY LEFT BLANK Revision E Page C-16 May 31, 2006...
Page 121 FreeFlight 2101 I/O Approach Plus GPS Navigation System APPENDIX D SUPPLEMENTAL TYPE CERTIFICATES FLIGHT MANUAL SUPPLEMENTS...
Page 123: Appendix D - Stcs And Flight Manual Supplements
FreeFlight 2101 I/O Approach Plus GPS Navigation System APPENDIX D - STCs and Flight Manual Supplements Supplemental Type Certificates and the FAA approved Flight Manual Supplements for the FreeFlight 2101 I/O Approach Plus will be posted to FreeFlight's FTP site when they become available.
Page 124 FreeFlight 2101 I/O Approach Plus GPS Navigation System THIS PAGE INTENTIONALLY LEFT BLANK Revision E Page D-2 May 31, 2006...
Page 127 Serial No. LJ-207 This supplement must be attached to the FAA approved Beech 65-A90 FAA Airplane Flight Manual when the FreeFlight 2101 I/O Approach Plus GPS Navigation System has been installed in accordance with FAA STC SA09363SC . The information contained herein supplements or supersedes the basic Airplane Flight Manual only in those areas listed.
Page 128 FreeFlights Systems. Airplane Flight Manual Supplement 3700 Interstate 35 for Beech Model 65-A90 Aircraft Waco Texas, 76706 with FreeFlight 2101 I/O App Plus GPS TABLE OF CONTENTS TABLE OF CONTENTS ......................2 LOG OF REVISIONS ........................3 GENERAL DESCRIPTION ......................4 SECTION IV - LIMITATIONS ....................5 SECTION V - NORMAL PROCEDURES..................7...
Page 129: Log Of Revisions
FreeFlights Systems. Airplane Flight Manual Supplement 3700 Interstate 35 for Beech Model 65-A90 Aircraft Waco Texas, 76706 with FreeFlight 2101 I/O App Plus GPS LOG OF REVISIONS Revision Page Subject Approval Date Initial Release See page one FAA Approved Page 3 of 14...
Page 130: General Description
The FreeFlight 2101 I/O Approach Plus GPS Navigation System will provide position accuracies commensurate with selective availability, provided that the system is receiving adequate satellite signals. The FreeFlight 2101 I/O Approach Plus has demonstrated that it is capable of and has met the accuracy requirements of: VFR/IFR domestic en route, terminal and non-precision instrument approach operation within the U.S.
Page 131: Section Iv - Limitations
NOTE: Many of the waypoints identified in the Jeppesen NavData database and used by the 2101 I/O Approach Plus to fly the approach may be unnamed in the published Terminal Procedures. These included waypoints such as the intersection of two radials, DME positions, waypoints located on a DME Arc, turn waypoints, or waypoints to indicate a Final Approach Fix (FAF).
Page 132 Waco Texas, 76706 with FreeFlight 2101 I/O App Plus GPS The FreeFlight 2101 I/O Approach Plus can only be used for approach guidance if the reference coordinate datum system for the instrument approach is WGS-84 or NAD-83. (The NavData data base used in the FreeFlight 2101 I/O Approach Plus only contains WGS-84 geodetic datum referenced data).
Page 133: Section V - Normal Procedures
(Green) (On the NAV/GPS annunciator) This annunciator lights when the navigation selector switch is in the GPS position to indicate that navigation data displayed on the HSI is from the FreeFlight 2101 I/O Approach Plus System. NAV (White) (On the NAV/GPS annunciator) This annunciator lights when the navigation selector switch is in the NAV position to indicate that Navigation data displayed on the HSI is from the VHF NAV system.
Page 134 Fix (FAF)), and the aircraft track is within 70 degrees of the inbound course. Two annunciators, located below the 2101 I/O Approach Plus RDU on the center instrument panel, and controlled by the NAV/GPS switch, indicate whether the GPS roll steering signal...
Page 135 HSI Display: Cross track deviation, TO/FROM, and navigation valid flag data from the VOR, ILS or Trimble 2101 I/O Approach Plus can be displayed on the HSI indicator depending on the state of the NAV/GPS. To display left/right cross track deviation, TO/FROM and flag valid information on the HSI indicator from the FreeFlight 2101 I/O, place the navigation selector switch to the GPS position.
Page 136 (FAF to MAP) when sequenced to the FAF, the Trimble 2101 I/O Approach Plus will automatically place the unit in HOLD mode (HLD) at or abeam the FAF and prompt the pilot to enter the outbound course from the FAF.
Page 137 All missed approach procedures should be executed manually. 9. Once a destination airport has been established with an ETA, the FreeFlight 2101 I/O Approach Plus will automatically determine RAIM availability at the destination. The prediction shall cover a time period ±15 minutes from the ETA, in intervals of 5 minutes.
Page 138 FreeFlight 2101 I/O App Plus GPS POWER A 2 amp circuit breaker labeled GPS, located first officer’s instrument panel circuit breaker panel, powers the FreeFlight 2101 I/O Approach Plus Navigation System. A 1 amp circuit breaker labeled ADS Computer, located first officer’s instrument panel circuit breaker panel, powers the ADC-200.
Page 139: Section Vi - Emergency Procedures
RAIM: In enroute and terminal operation, continue to navigate using the Trimble 2101 I/O Approach Plus, or revert to an alternate means of navigation appropriate to the route and phase of flight. When continuing to use GPS navigation, position must be verified every 15 minutes using another IFR approved navigation system.
Page 140: Section Vii - Faa Approved Performance
FreeFlights Systems. Airplane Flight Manual Supplement 3700 Interstate 35 for Beech Model 65-A90 Aircraft Waco Texas, 76706 with FreeFlight 2101 I/O App Plus GPS SECTION VII - FAA APPROVED PERFORMANCE No Change FAA Approved Page 14 of 14 Date: 10/27/97...
Page 141 FreeFlight 2101 I/O Approach Plus GPS Navigation System APPENDIX E LOCAL GEODETIC REFERENCE DATUMS...
Page 143 FreeFlight 2101 I/O Approach Plus GPS Navigation System APPENDIX E - Local Geodetic Reference Datums DATUM LOCALITY Adindan Ethiopia, Mali, Senegal, Sudan Somalia Ain El Abd 1970 Bahrain Is. Alaska (NAD-27) Alaska Alaska/Canada (NAD-27) Alaska/Canada Anna 1 Astro 1965 Cocos Is.
Page 144 FreeFlight 2101 I/O Approach Plus GPS Navigation System Cuba (NAD27) Cuba Cyprus Isle of Cyprus Djakarat (Batavia) Sumatra Is. DOS 1968 Gizo Is., Solomon Is. Easter Island 1967 Easter Island Egypt Egypt European 1950 mean Austria, Denmark, Finland, France, Germany, Gibralter,...
Page 145 FreeFlight 2101 I/O Approach Plus GPS Navigation System Luzon Philippines except Mindanao Mahe 1971 Mahe Is., Seychelles Massawa Eritrea Merchich Morocco Mexico (NAD27) Mexico Midway Astro '61 Midway Is. Mindanao Mindanao Is. Minna Nigeria Montjong Lowe Celebes Is. Nahrwan Saudia Arabia...
Page 146 FreeFlight 2101 I/O Approach Plus GPS Navigation System South Asia Singapore Provisional South Chilean 1963 South Chile S.E. Asia (Indian) Bangladesh, India, Kampuchea, Laos, Nepal, Thailand, Vietnam Southeast Base Porto Santo, Maderia Is. Southwest Base Azores Tananarive Observatory '25 Madagascar...
Page 148 3700 Interstate 35 S. Waco, TX 76706-3756 1 (254) 662-0000...
Page 150 3700 Interstate 35 S. Waco, TX 76706-3756 1 (254) 662-0000...
Page 152 Assembly Instructions for FreeFlight 2101 I/O Plus Installation Manual P/N 82882, Rev E Print 2-sided for 8½" X 11" sheets and 1-sided for 11" X 17" sheets. Fold 11" x 17" as shown. Use card stock for dividers, front cover & back cover.

FreeFlight 2101 I/O Approach Plus Installation And Checkout Manual

Quick Links

Need help?

Questions and answers

Related Manuals for FreeFlight 2101 I/O Approach Plus

Summary of Contents for FreeFlight 2101 I/O Approach Plus

Table of Contents
