1.3.1.1 GPS Receiver
TYPE
ACQUISITION TIME
POSITION UPDATE RATE
DYNAMICS
ACCURACY
Position
Velocity
Altitude
Time
1.3.2

GPS Antenna (P/N 81194)

TSO COMPLIANCE
ENVIRONMENTAL COMPLIANCE
PHYSICAL DIMENSIONS
Height
Width
Length
WEIGHT
TEMPERATURE
ALTITUDE RANGE
MOUNTING
POWER REQUIREMENTS
SPEED RATING
CONNECTOR
* Use of the GPS antenna for IFR installations in aircraft equipped with satellite communication equipment
should be tested to ensure no interference exists between the SATCOM equipment and the GPS antenna.
Revision E
May 31, 2006
FreeFlight 2101 I/O Approach Plus GPS Navigation System
** Selective Availability not implemented
L1 Frequency (1575 MHz), C/A Code,
Twelve Channel
1.5 to 3.5 minutes
5 per second
800 knots, 6g (tracking)
15 meters RMS**
0.1 knots steady state**
35 meters RMS** (MSL)
UTC to the nearest microsecond
C129, C144 *
See Appendix A
0.60 in (1.52 cm)
3.00 in (7.62 cm)
4.70 in (11.94 cm)
0.375 lb (0.17 kg)
-55°C to +85°C
-100 ft to +55,000 ft
External
+5 Vdc @ 40 mA max from RDU
1300 knots IAS
TNC
Page 1-5
