B.6.5
Data Output Format Example
The following is an example of the data output for the R0 and R1 formats. It is also the first part of the K0, K1, X0,
and X1 formats.
<STX>AN 37 2164
BW 121 5516
C137
D128
E071227
F0534
GR0018
HR0003
I1384
J11
KAUS
L1389
M0000
P005
QE158
c001
T-----------
d057
e059
i10/19/89
j13:52:12
s020000
Revision E
May 31, 2006
FreeFlight 2101 I/O Approach Plus GPS Navigation System
EXAMPLE
LAT North 37° 21.64 min
LON West 121° 55.16 min
TK 137°
GS 128 knots
DIS 712.27 nm
ETE 5 hrs, 34 min
XTK 0.18 nm Right
TKE 0.3° Right
DTK 138.4°
Active Leg #11
Destination Waypoint AUS
BRG 138.9°
PTK 0.0 nm
Position Error 0.05 nm
Magnetic Variation 15.8° East
Time Since Last Solution 0.1 sec
No Warnings are Present
MSA 5,700 ft
MESA 5,900 ft
Date October 19, 1989
Time 13:52:12 UTC
Software Code 020000
DESCRIPTION
Page B-17
