1.4

PARTS AND EQUIPMENT

1.4.1

FreeFlight 2101 I/O Approach Plus GPS Receiver Display Unit

The hardware required for proper installation is available in one of the Installation Kits listed under Section 1.4.2.
Listed below are the parts and equipment required with the FreeFlight 2101 I/O Approach Plus.
TPN
81440-XX
81448-20 or -21
1.4.2

Installation Kit

The Installation Kit contains decals, labels, NavData subscription form, manuals, appropriate connectors, and
installation hardware. This is provided as a convenience to the installation agency and FreeFlight reserves the right
to substitute equivalent parts without prior notice. The contents are listed below:
P/N DESCRIPTION
81194 * GPS Antenna, ARINC 743 Hi Speed
16248-11 ** GPS Antenna/Preamp
80116 Antenna Mounting Gasket
16940 NavData Information and Subscription
80252 37-Pin Connector w/pins
80254 66-pin Connector w/pins
24633-0016 Connector Backshell, 90° 37-pin
25039-0001 Connector, Backshell, 90° 66-pin
81822-DOC Install Advisement, Cooling Kit
26479-0494 Connector TNC, 90°
80399 GPS Antenna Template
81515-00 Forced-Air Cooling Kit
* Use of the GPS antenna for IFR installations in aircraft equipped with satellite communication equipment
should be tested to ensure no interference exists between the SATCOM equipment and the GPS antenna.
** Installations utilizing this antenna are limited to aircraft not equipped with Satellite Communications equipment.
Notes:
1. Use Crimp Tool M22520/2-01 and positioner M22520/2-06.
2. Use Crimp Tool Amp P/N 220015-1.
Revision E
May 31, 2006
FreeFlight 2101 I/O Approach Plus GPS Navigation System
QTY DESCRIPTION
1 GPS Receiver/Display Unit
1 FreeFlight 2101 I/O Approach Plus Installation Kit
QTY 81448-20 -21
1 -
- 1
- 1
1 1
1 1 Note 1
1 1 Note 1
1 1
1 1
1 1
2 2 Note 2
- 1
1 1
Page 1-7
