Features

•
STM32F103ZGT6 Arm
flash memory and 96 Kbytes of SRAM, in a 144-pin TQFP package
•
240 x 320.pixel TFT color LCD
2
•
I S audio DAC, with stereo output
•
Both A- and B-type smartcard support
•
IrDA transceiver
•
512 Kx16 SRAM, 64- or 128-Mbit serial, 512-Mbit or 1-Gbit NAND, and 128-Mbit NOR
flash memories
2
•
I C/SMBus compatible serial interface with temperature sensor
•
RTC with backup battery
•
4 color LEDs
•
Reset, wakeup, tamper, and user push-buttons
•
4-way joystick with selection
•
Board connectors:
–
–
–
–
–
–
–
–
–
–
–
–
•
Three 5 V power supply options: power jack, USB connector, or daughterboard
a. Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
®(a)
5V power jack
USB 2.0 FS Type-B
Two RS-232 channels with RTS/CTS handshake support on one channel
Stereo audio jack
Three ADC inputs
CAN 2.0 A/B compliant
Smartcard socket
microSD™ card holder with 128-Mbyte card
Coin-battery cell holder for power backup
JTAG and ETM trace debugger connector
Motor-control interface
Extension headers for daughterboard or wire-wrap board
®
Cortex -M3 core-based microcontroller with 1 Mbyte of
