Connectors
Table 25. Daughterboard extension header (CN10) (continued)
Pin # Description
41 PB4
43 PB6
45 PB8
47 PE0
49 D5V
51 PE4
53 PE6
55 PC14
57 PF0
59 GND
61 PF2
63 PF4
65 PF6
67 PF8
69 +3V3
2 PC6
4 PC8
6 PA8
8 PA10
10 GND
12 PA11
14 PA13
16 PA15
18 PC11
20 PC12
22 PD1
24 PE1
26 PD3
26/45
Alternative function
Debug_TRST/MC
I2C_SCL/QST
CAN_RX
FSMC_BLN0
-
Trace_D1/FSMC_A20
Trace_D3/FSMC_A22
OSC32_IN
FSMC_A0
-
FSMC_A2
FSMC_A4
LD2
LD4
-
Smartcard/MC/I2S_MCK
MicroSDcard_D0/MC
MCO/LCD_backlight/QST
USART1_RX
-
USB_DM
Debug TMS
Debug TDI
IrDA_RX/MicroSDcard_D2
MicroSDcard_CLK
FSMC_D3
FSMC_BLN1
Joystick_Down
UM0488 Rev 7
How to disconnect from function block on
STM3210E-EVAL board
Disconnect the STM3210E-EVAL Evaluation board
from the motor-power drive board.
Keep JP19 OFF.
Disconnect the STM3210E-EVAL Evaluation board
from the QST board.
Remove R32.
-
-
-
-
Remove R135 and keep the JP9 jumper ON.
-
-
-
-
Remove R96.
Remove R98.
-
Disconnect the STM3210E-EVAL Evaluation board
from the motor-power drive board.
Keep JP15 OFF.
Disconnect the STM3210E-EVAL Evaluation board
from the motor-power drive board.
Remove the SD card from the microSD™ card holder.
Disconnect the STM3210E-EVAL Evaluation board
from the QST board.
Remove R36.
-
Remove R81.
-
-
Remove the SD card from the microSD™ card holder.
Remove R89.
Remove the SD card from the microSD™ card holder.
-
-
Remove R100.
