ST STM3210E-EVAL User Manual page 29

UM0488
Table 26. Daughterboard extension header (CN11) (continued)
Pin # Description
61 PA1
63 PC3
65 PC1
67 PF10
69 +3V3
2 PG8
4 PG6
6 PG4
8 PG2
10 GND
12 PD13
14 PD11
16 PD9
18 PB15
20 PB14
22 PB12
24 PB10
26 PE14
28 PE12
30 GND
32 PD14
34 PE10
36 PE8
38 -
40 PG0
42 PF15
44 PF13
46 PF11
48 -
Alternative function
MC/USART2_RTS
MC/BNC3
MC/BNC1
LCD_CS
-
User button B4
FSMC_INT2
FSMC_A14
FSMC_A12
-
FSMC_A18
FSMC_A16
FSMC_A14
I2S_DIN
USB disconnect
Smartcard_CK/MC/I2S_CMD
Smartcard_IO
FSMC_D11
FSMC_D9
-
FSMC_D0
FSMC_D7
FSMC_D5
-
FSMC_A10
FSMC_A9
FSMC_A7
QST/microSD™ card
detection
-
UM0488 Rev 7
How to disconnect from function block on
STM3210E-EVAL board
Disconnect the STM3210E-EVAL Evaluation board
from the motor-power drive board.
Disconnect the STM3210E-EVAL Evaluation board
from the motor-power drive board.
Disconnect the analog signal from BNC3.
Disconnect the STM3210E-EVAL Evaluation board
from the motor-power drive board.
Disconnect the analog signal from BNC1.
-
-
Remove R106.
Keep JP7 OFF.
-
-
-
-
-
-
-
Connect pin1 of JP14 to pin2.
Disconnect the STM3210E-EVAL Evaluation board
from the motor-power drive board.
Remove R94.
-
-
-
-
-
-
-
-
-
-
Disconnect the STM3210E-EVAL Evaluation board
from the QST board. Remove the SD card from the
card holder (CN13).
-
Connectors
29/45
