Connectors
6.11

USB Type-B connector (CN14)

Pin number
1
2
3
6.12

Audio jack (CN15)

A 3.5 mm stereo audio jack (CN15) connected to the audio DAC is available on the
STM3210E-EVAL board.
6.13

TFT LCD connector (CN16)

One 30-pin male header is available on the board to connect the LCD module board MB895
to the FSMC interface of the STM32F103ZGT6. Refer to
devices on page 18
6.14

Power connector (CN17)

The STM3210E-EVAL board can be powered from a DC 5 V power supply via the external
power supply jack (CN17) shown in
32/45

Figure 13. USB Type-B connector (CN14) (Top view)

Table 29. USB Type-B connector (CN14)

Description
VBUS (Power)
PA11
PA12
for details.

Figure 14. Power supply connector (CN17) (Front view)

DC +5V
UM0488 Rev 7
Pin number
4
5,6
-
Section 5.17: Display and input
Figure 14. The central pin of CN17 must be positive.
MS32861V1
Description
GND
Shield
-
GND
UM0488
MS32862V1
