364xS User's Manual
4. Plug and seal the ports. Make sure that when the installation has been completed, the ports are properly
sealed against entry of water and corrosive vapors and gases.
Cables, cable gland and unused port plug must be in accordance with the intended type of protection (e.g.
intrinsically safe, explosion proof, etc.) and degree of protection (e.g. IP6x or NEMA 4x). In particular, for
explosion proof installation, plug the unused opening with a plug certified for explosion containment.
5. Install the housing cover, turn it to seat O-ring into the housing and then continue to hand tighten until
the cover contacts the housing metal-to-metal. In EEx-d (Explosion Proof) installation, lock the cover
rotation by turning the set nut (use the 2 mm Allen key supplied with the instrument).
For further information find the relevant instruction manuals searching for the keyword "IM/*36*" on
www.abb.com or from local ABB representatives.

Check the installation

Before applying power and pressure, perform the following checks.
√
Installation environment conforms to the transmitter specification for ambient conditions
The transmitter is mounted securely
The transmitter is properly grounded
The input power voltage matches the transmitter nominal input voltage
The plugs/vents and process connections are tightened as specified
The proper electrical adapter are installed and are tightened as specified
The red plug on the electical input not used is replaced with a proper plug
The cover is tightened up to metal to metal contact with the housing
All the requirements are satisfied if the transmitter is working in hazardous area

Apply power

The transmitter will start up automatically at the power up.

Start up

The transmitter has default parameter settings that are sufficient for many situations and start up of the
instrument. However, review the configuration chapter for the default parameter settings values and the
parameter changes procedures.
WARNING !
Check
21
Installation
