364xS User's Manual
Display indication
Calibrate
Sensor Trim
Lower sensor trim
Upper sensor trim
Output Trim
Set 4 mA
Set 20 mA
Reset to Factory Trim
Diagnostics
Diagnostics
PV
HART Eng. Output
Output current
Output %
Permanent Totalizer
Batch Totalizer
Static Pressure
Sensor temperature
Loop Test
Set 4 mA
Set 20 mA
Set custom value

Digital LCD Integral Display view setting

To view the menu in a specific language:
Navigate the Digital LCD Integral Display menu, select
available. To modify select
OK.
Digital LCD Integral Display Keys sequence to set the language: 3 – 1 – Edit
To modify the Operator view:
Navigate the Digital LCD Integral Display menu, select
available. To modify select
and down keys and confirm with OK.
One Line
One Line + Bargraph
Two Lines
Two Lines + Bargraph
This function provides all the Calibration settings
This function provides the trimming of the sensor
Set the lower Sensor Trim point
Set the upper Sensor Trim point
This function provides all the trimming of the
current output
Trim the output current to 4 mA when the action is
performed
Trim the output current to 20 mA when the action is
performed
Set the output current Trim and the Sensor Trim at
the Calibration performed in the factory during the
trasmitter manufacturing
This function provides all the Diagnostics
information
This function provides all the Main Diagnostics
information
Monitor the PV value
Monitor the HART Engineering Output value
Monitor the Current Output value
Monitor the Percentage Output value
Monitor the Permanent Totalizer value
Monitor the Batch Totalizer value
Monitor the Static Pressure value
Monitor the Sensor temperature value
This function provides to force the output current at
a specific value
Set the output to 4 mA
Set the output current to 20 mA
Set the output current to a defined value
Edit then scroll the desired language with the up and down keys and confirm with
Edit then scroll the desired Operator view (see the following table) with the up
to view the Variable 1 as defined in the Display
to view the Variable 1 as defined in the Display and the Bargraph
proportional with the variable full scale
to view the Variable 1 and the Variable 2 as defined in the Display
to view the Variable 1 and the Variable 2 as defined in the Display
and the Bargraph proportional with the variable full scale
Description
Display > Language, and the used language will be
Display > Operator View, and the used view will be
44
Level Type
Main Menu
Sub Menu
Utility Numerical
Utility Numerical
Sub Menu
Utility Numerical
Utility Numerical
Utility Enumerated
Main Menu
Sub Menu
Utility Numerical
Utility Numerical
Utility Numerical
Utility Numerical
Utility Numerical
Utility Numerical
Utility Numerical
Utility Numerical
Sub Menu
Utility Auto Adjust
Utility Auto Adjust
Utility Manual Adjust
Operation
