ABB 2600T Pressure Transmitter Series User Manual page 26

364xS User's Manual
Units for Flow variable
3
m /h cubic meter per hour
gal/s US gallons per second
Mgal/d mega US gallons per day
L/s liter per second
ML/d megaliter per day
CFS cubic feet per second
3
ft /d cubic feet per day
3
m /s cubic meter per second
3
m /d cubic meter per day
ImGal/h Imperial Gallons per hour
ImGal/d Imperial Gallons per day
g/s gram per second
g/min gram per minute
g/h gram per hour
kg/s kilogram per second
kg/min kilogram per minute
kg/h kilogram per hour
kg/d kilogram per day
t/min ton per minute
t/h ton per hour
t/d ton per day
lb/s pound per second
lb/min pound per minute
lb/h pound per hour
Units for Mass and Volume variable
L liter
hl hectoliter
3
in cubic inch
3
ft cubic feet
3
yd cubic yard
gallon US gallon
ImpGal Imperial gallon
bushel bushel
bbl barrel
bbl liq barrel liquid
SCF standard cubic feet
Units for Density
degB hv degrees Baum heavy
degB lt degrees Baum light
degAPI degrees API
SGU specific gravity units
3
g/cm gram per cubic meter
3
kg/m kilogram per cubic meter
lb/gal pound per US gallon
Units for Level
m meter
cm centimeter
mm millimiter
Other Units
N Newton
mA milliamperes
V volts
Digital LCD Integral Display Keys sequence to change the unit on the Display: 3 – 7 – 1
To change the PV unit in the transmitter:
Navigate the Digital LCD Integral Display menu, select
Engineering Unit, and the used unit will be available. To modify select
the following table) with the up and down keys and confirm with
lb/d pound per day
STon/min short ton per minute
STon/h short ton per hour
STon/d short ton per day
LTon/h long ton per hour
LTon/d long ton per day
3
Nm /h Normal cubic meter per hour
NL/h Normal liter per hour
SCFM standard cube feet per minute
CFH cubic feet per hour
3
m /min cubic meter per minute
bbl/s barrel per second
bbl/min barrel per minute
bbl/h barrel per hour
bbl/d barrel per day
gal/h US gallon per hour
ImGal/s Imperial gallon per second
L/h liter per hour
gal/d US gallon per day
CFM cubic feet per minute
GPM US gallon per minute
L/min liter per minute
ImGal/m Imperial gallon per minute
3
Nm Normal cubic meter
NL Normal liter
g gram
kg kilogram
t ton
lb pound
STon short ton
LTon long ton
oz ounce
3
m cubic meter
3
lb/ft pound per cubic feet
g/ml grams per milliliter
kg/L kilograms per Liter
g/L grams per Liter
3
lb/in pound per cubic inch
3
STn/yd short ton per cubic yard
degTwad degrees Twaddell
ft feet
in inch
mV millivolts
% percentage
Device Config > Rerange
Edit
OK.
> Rerange no pressure
then scroll the desired unit (see
Configuration
26
>
