364xS User's Manual
3
m /h cubic meter per hour
gal/s US gallons per second
Mgal/d mega US gallons per day
L/s liter per second
ML/d megaliter per day
CFS cubic feet per second
3
ft /d cubic feet per day
3
m /s cubic meter per second
3
m /d cubic meter per day
ImGal/h Imperial Gallons per hour
ImGal/d Imperial Gallons per day
g/s gram per second
g/min gram per minute
g/h gram per hour
kg/s kilogram per second
kg/min kilogram per minute
kg/h kilogram per hour
kg/d kilogram per day
t/min ton per minute
t/h ton per hour
t/d ton per day
lb/s pound per second
lb/min pound per minute
lb/h pound per hour
To set the Permanent Totalizer Engineering units:
Navigate the Digital LCD Integral Display menu, select
Engineering Unit, and the used Permanent Totalizer Engineering Units will be available. To modify select
Edit then scroll the desired unit (see the following table) with the up and down keys and confirm with OK.
L liter
hl hectoliter
3
in cubic inch
3
ft cubic feet
3
yd cubic yard
gallon US gallon
ImpGal Imperial gallon
bushel bushel
bbl barrel
bbl liq barrel liquid
SCF standard cubic feet
Digital LCD Integral Display Keys sequence to set the Permanent Totalizer Engineering units: 4 – 3 – 4 – 1 – Edit
To set the Permanent Totalizer Custom unit:
Navigate the Digital LCD Integral Display menu, select
Custom Unit, and the used Permanent Totalizer Custom Units will be available. To modify select
scroll the desired alphanumeric symbol with the up and down keys and confirm with
operation for the six digits and confirm with
Digital LCD Integral Display Keys sequence to set the Permanent Totalizer Custom units: 4 – 3 – 4 – 2 – Edit
To set the Permanent Totalizer Conversion Factor:
Navigate the Digital LCD Integral Display menu, select
Conversion Factor, and the used Permanent Totalizer Custom Units will be available. To modify select
then scroll the desired value with the up and down keys and confirm with
seven digits and confirm with
Note: the minimum and the maximum values to introduce are indicated on the display.
Digital LCD Integral Display Keys sequence to set the Permanent Totalizer Conversion Factor: 4 – 3 – 4 – 3 – Edit
lb/d
STon/min
STon/h
STon/d
LTon/h
LTon/d
3
Nm /h
NL/h
SCFM
CFH
3
m /min
bbl/s
bbl/min
bbl/h
bbl/d
gal/h
ImGal/s
L/h
gal/d
CFM
GPM
L/min
ImGal/m
3
Nm
NL
g
kg
t
lb
STon
LTon
oz
3
m
OK.
OK.
pound per day
short ton per minute
short ton per hour
short ton per day
long ton per hour
long ton per day
Normal cubic meter per hour
Normal liter per hour
standard cube feet per minute
cubic feet per hour
cubic meter per minute
barrel per second
barrel per minute
barrel per hour
barrel per day
US gallon per hour
Imperial gallon per second
liter per hour
US gallon per day
cubic feet per minute
US gallon per minute
liter per minute
Imperial gallon per minute
Totalizer > Totalizer setting
Normal cubic meter
Normal liter
gram
kilogram
ton
pound
short ton
long ton
ounce
cubic meter
Totalizer > Totalizer setting
Totalizer > Totalizer setting
Next.
30
> Permanent Eng. Unit
> Permanent Eng. Unit
Edit then
Next. Repeat the
> Permanent Eng. Unit
Edit
Repeat the operation for the
Configuration
>
>
>
