Status Lights
3
When lit, a "status" light indicates successful communication between
the E-Que card and a connected device such as an active antenna or
splitter.
Each of the E-Que card's 8 yellow "status" lights corresponds to one of
8 ports to which devices can be connected.

LAN Data Light

4
The green "LAN DATA" light illuminates to indicate there is data
passing through the ethernet port.

LAN Link Light

5
The amber "LAN LINK" light illuminates to indicate a connection to the
LAN port.

E-QUE CARD REAR CONNECTIONS

The E-Que card rear card contains eleven RJ45 connectors; 8 E1/T1
ports, 2 DECT sync ports and a LAN port.
