2 - 6
STATUS LIGHTS
4
OK Light
When flashing, the "OK" light indicates that the CPU card is
successfully communicating with the Eclipse Configuration System
(ECS).
IPC (Interprocessor Communication) Light
The "interprocessor communication" (IPC) light only operates when
there are two CPU cards in the matrix. When lit, the light indicates that
the two CPU cards are exchanging information.
Master Light
An Eclipse Median system can have two CPU cards, although the
system will operate with only one. If the primary card becomes
unavailable for any reason, the second card can serve as backup while
the primary card is repaired or replaced.
The "master" light illuminates on whichever CPU card is currently
serving as master. If there is a backup CPU card in the matrix, its
"master" light will not illuminate if the primary card is acting as master.
LAN A Light
When you connect a local area network (LAN) to the matrix's "LAN A"
port, the CPU card's "LAN A" LED lights to indicate a connection to the
Eclipse matrix LAN A.
LAN B Light
When you connect a second local area network to the matrix's "LAN B"
port, the CPU card's "LAN B" LED lights to indicate a connection to the
Eclipse matrix LAN B.
Sync Light
When you connect multiple Eclipse matrices together, the "sync" light
illuminates to indicate that the matrices are connected and
synchronized.
SI Light
The "SI" light flashes to indicate communications activity.
CONFIGURATION "CONFIG" BUTTON
5
The CPU card can hold four complete system configurations in its
operational memory. When you tap the "CONFIG" button, the number
Vitec Group Communications
Eclipse Median Instruction Manual
