PINOUT FOR GENERAL PURPOSE INPUT CONNECTOR
This addendum corrects the General Purpose Input connector pinout information given in the
Eclipse-32 (part 810315Z), Eclipse PiCo (part 810348Z), Eclipse Median (part 810347Z) and Eclipse
Omega (part 810390Z) manuals installation information.
DB-25 Female Connector
PIN
DESCRIPTION
1
Logic Input 1
Logic Input 2
2
3
Logic Input 3
4
Logic Input 4
N/A
5
N/A
6
N/A
7
N/A
8
Ground
9
10
Ground
Ground
11
12
Ground
13
Ground
14
Logic Input 5
15
Logic Input 6
16
Logic Input 7
Logic Input 8
17
18
N/A
19
N/A
20
N/A
21
N/A
22
Voltage In+
23
Voltage In+
24
Voltage In-
25
Voltage In-
GPI Pinout Addendum
Logic Input 1
Logic Input 2
Logic Input 3
Logic Input 4
Figure 1: Pinout for General Purpose Inputs Connector
1
2
3
4
5
6
8
Ground
9
Ground
10
Ground
11
Ground
12
Ground
13
1
Eclipse V5.0
Addendum to Manuals
Logic Input 5
14
Logic Input 6
15
Logic Input 7
16
Logic Input 8
17
18
19
7
20
21
V IN+
22
V IN+
23
V IN–
24
V IN–
25
© Clear-Com Communication Systems
