Introduction

The FC-2000 is an expandable multi-zone Fire Alarm Control Panel

Description

designed with maximum flexibility and modularity as a basic requirement.
The heart of the system is the Central Processor Unit (CPU-2000) module,
which monitors and directs the actions of all other modules in the system.
Fifteen other modules may be installed in various configurations. Internal
communications are accomplished over a high-speed serial bus.
The CPU-2000 is provided with the Basic Equipment package. This
module provides two Style Z and/or Style Y indicating appliance circuits,
Form-C alarm and trouble contacts, remote station alarm and trouble
outputs, and a municipal central box output.
A Main Power Supply (MPS-24A or MPS-24B) and an Indicating Zone
Module (IZM-8) must be added to make the basic system functional.
The basic system can be expanded using one or more of the following
optional modules or boards:
All manuals and user guides at all-guides.com
IZM-8 Initiating Zone Module
IZE-A Initiating Zone Expander
ICM-4 Indicating Circuit Module
ICE-4 Indicating Circuit Expander
AVPS-24 Audio Visual Power Supply
CRM-4 Control Relay Module
CRE-4 Control Relay Expander
ARM-4 Auxiliary Relay Module
VCM-4 Voice Control Module
VCE-4 Voice Control Expander
DCM-2 Dual Channel Module
TCM-2 Time Control Module
TCM-4 Time Control Module
AIM-200 Addressable Intelligent Module
FFT-7 Fire Fighter's Telephone
AMG-1 Audio Message Generator
Installation—Installing the FC-2000 3
