To mount the Main Power Supply (MPS-24A or MPS-24B), complete the

Mounting the

following steps and refer to Figure 15.

Main Power

Supply in the

1. Place the MPS-24A or MPS-24B into the cabinet, ensuring that the

Cabinet

2. Secure the bottom of the MPS-24A to the bottom cabinet support with

C A B -x3

Step 1

Place the MPS-24A into the bottom of the cabinet,

ensuring that the upper bracket engages the

support bracket on the CAB-x3 cabinet.

Figure 15: Mounting the Main Power Supply in the CAB-x3

22 Installation—Installing the FC-2000

All manuals and user guides at all-guides.com

upper bracket engages the support bracket on the cabinet.

the two screws provided. The MPS-24B requires only one screw.

C A B -x3

Step 2

Secure the bottom on the power supply to the

bottom cabinet support with the two screws

provided.

mpsmount
