Mounting Optional Module Expanders - Johnson Controls FC-2000 Installing

1. Remove one module support screw and set it aside for later use.
Mounting
Optional
2. Replace screw with one module standoff.
Module
3. Repeat Steps 1 and 2 for the three remaining screws on the module.
Expanders
4. Insert pins on the expander board into connector on module and press
5. Install the four screws removed earlier through the back of the
26 Installation—Installing the FC-2000
All manuals and user guides at all-guides.com
the two boards together, ensuring that the pins are properly aligned.
expander board and into the standoffs.
Step 1
Module
Step 4
Module Expander
Board
Figure 18: Mounting Optional Module Expanders
Step 2
Module
Step 5
M odule Expander
Board
step5ex
