The optional Main Power Meter (MPM-2) can be installed on the Main

Installing an

Power Supply (MPS-24A only). One scale on the MPM-2 provides an

Optional Main

indication in volts of the voltage across the batteries in the system. A

Power Meter

second scale indicates the battery charging current in amps. Complete the

following steps and refer to Figure 33 to install the MPM-2.

1. Remove the two screws in the bottom left-hand corner of the

2. Thread the two standoffs provided into the holes vacated by the two

3. Complete the installation of the MPM-2 by plugging the female

All manuals and user guides at all-guides.com

MPS-24A.

screws just removed. Place the MPM-2 assembly over the standoffs

and secure with the two original screws

connector on the meter cable into plug P7 on the MPS-24A.

Installation—Installing the FC-2000
