General Information
For information on...
Universal Zone Coder
Voice Alarm Systems & Voice
Evacuation
Networking

1.3 Introduction to the Control Panel

The IFC-3030 is an intelligent Fire Alarm Control Panel (FACP) with features suitable for most
applications. The JCPU-3030 comes with a front display/keypad option, which allows
programming and viewing options at the panel.
There are two basic configuration options for the IFC-3030. It can be ordered with:
• a front display/keypad, which allows programming and viewing options at the panel, or
• no display keypad.
This manual gives instructions using the front display/keypad.
Displayless Mode
When there is no keypad/display at the IFC-3030, the panel is controlled by remote annunciators.
VeriFire™ Tools programming is required. The displayless panel has four buttons on its circuit
board that are service-level switches for local operation should it become necessary. They are the
only buttons, and are clearly marked with ACK for Acknowledge, SIGSIL for Signal Silence,
SYSRST for System Reset, and LAMP TEST. These buttons are mainly for installer use: the
operator should utilize a remote annunciator for these functions, if possible. The status indicator
LEDs on the circuit board are the same as on the display/keypad (refer to "The Display/Keypad" on
page 10 of this manual).
Refer to VeriFire™ Tools or the JNCA manual for information on programming without an IFC-
3030 display/keypad.

1.4 Operating Features

• Alarm Verification selection, to reduce unwanted alarms
• Positive Alarm Sequence (PAS) and Presignal per NFPA 72
• Silence Inhibit timer and Auto Silence timer for Notification Appliance Circuits (NACs)
• March time/Temporal code for Panel Circuit modules
• Programmable Signal Silence, System Reset, and Alarm Activate functions through monitor
modules
• Automatic time-of-day and day-of-week control functions, with holiday option
• AWACS (Advanced Warning Addressable Combustion Sensing) with nine field-adjustable
Pre-Alarm levels with programmable Control-By-Event (CBE)
• Operate automatic smoke or heat detector sounder/relay base on action Pre-Alarm level, with
general evacuation on alarm level
• Security alarm point option with separate audible signal code
• Centralized voice paging and audible alarm signaling options
8
Refer to...
UZC-256 Universal Zone Coder
UZC-256 Programming
XPIQ Manual
XPIQ Quad Intelligent Audio Transponder Technical Bulletin
VEC 25/50 Manual
Johnson Controls Voice Alarm System Manual
RM-1 Series Remote Microphone Installation Document
RM-1 Series Remote Microphone Technical Bulletin
ACT-2 Instructions
ACT-2 Audio Coupling Transformer Technical Bulletin
Noti•Fire•Net Version 4.0 Manual and Higher
NCM-W/F Instructions
IFW Internet Fire Workstation, Network Version 4.0 & Higher
Table 1.1 Supplemental Documentation (2 of 2)
Introduction to the Control Panel
IFC-3030 Operations Manual — PN 52026:C 08/05/2005
Part No.
15216
15976
51013
LIT-445235
50686
51869
51138
LIT-445212
51118
LIT-445225
51584
51533
52028
