Trim Ring For Cab-X3 Enclosures - Johnson Controls FC-2000 Installing

The TR-x3 Trim Ring consists of four pieces and is used when semi-flush
Trim Ring for
mounting the CAB-x3 enclosure (where x is the cabinet size, ranging
CAB-x3
from A to D).
Enclosures
Note: To semi-flush mount the cabinet, ensure ample room to allow the
Installing the
1. Place the top piece on the top of the backbox against the wall.
Trim Ring
2. Mark the wall with the locations to drill holes using the trim ring as a
3. Drill 3/16 inch diameter holes where marked. Holes should be drilled
4. Insert the provided wall anchors using a rubber mallet, tapping them
5. Secure the trim ring piece to the wall with the screws provided.
6. Repeat Steps 1-5 to install the left, right, and bottom trim ring pieces.
Note: The side trim ring pieces should have the holes nearest to the edge
All manuals and user guides at all-guides.com
door to swing fully open.
template.
to a depth of 1 inch.
in until they are flush with the wall surface.
Install the bottom piece last.
facing outward. See Figure 6.
Figure 6: Trim Ring Installation
TR-A3 = 19-5/8 in.
TR-B3 = 28-1/8 in.
TR-C3 = 36-3/4 in.
TR-D3 = 45-3/8 in.
trimring
Installation—Installing the FC-2000 15
