Johnson Controls FC-2000 Installing page 49

Harness
Connections for
the MPS-24B
TB1
All manuals and user guides at all-guides.com
MPS-24B Bell Power
Harness
(71093)
Connect to
J5 on the CPU
Blue Wire (+)
Black Wire (-)
1 2 3 4 5
Figure 35: Harness Connections for the MPS-24B
Connector Orientation
J 5 J 6
Power Ribbon
(71085)
P2
1 2 3 4 5
P3
JP3
JP1
Installation—Installing the FC-2000
CPU
(bottom view)
7-position end
Note position of
red wire at
8-position end.
Power Harness
(71086)
Connect to P2.
TB2
6
M P S -2 4 B
P4
P5
mps24bwr
49
