10.4.14 Installing double mechanical seal

Equipment and tools from the GEA Hilge assembly tool kit
•
•
•
•
•
•
•
Arrangements for double mechanical seals
Fig.73:
BA.10A.ADY.001.GB_1
20.07.2018
Hint!
This section applies to the installation of the double mechanical seal
in back-to-back and tandem arrangements
Spray bottle
Plastic mounting sleeve
Mounting sleeve
Loctite Type 243
Klüber paste UH1 96-402
Extractor
Socket wrench with plastic insert
Tandem double mechanical seal
(CONTRA I)
Fig.74: Double back-to-back mechanical seal
(CONTRA I)
Malfunctions / repairs
Repair
77
