Chapter 2
2. Use the long machine bolt, plastic washers, remaining washer, and nut to secure the
flood light assembly to the mounting brackets.
Side Mounting Bracket
1. Remove the roof bolts located just behind the antenna bracket mounting location on
the left and right sides of the roof.
Note:
Do not mount the light brackets to the same location as the antenna bracket.
2. Use the provided M6 bolts and washers to secure the side mounting brackets and
lights to the roof.
3. Insert the cleats (P/N 107-2610-021) onto each mounting bracket and secure the cleat
using the provided M5 hex key bolts.
106
