UM1902
Pin
number
4
+3.3V
5
SDMMC_CLK(PC12)
6.15

Power connector CN17

STM32746G-EVAL evaluation board can be powered from a DC 5 V power supply via the
external power supply jack (CN17), shown in
positive.
6.16

ST-LINK/V2-1 programming connector CN18

The connector CN18 is used only for embedded ST-LINK/V2-1 programming during board
manufacturing. It is not populated by default and not for end user.
6.17

MFX programming connector CN19

The connector CN19 is used only for MFX (Multi-Function eXpander) programming during
board manufacturing. It is not populated by default and not for end user.
6.18

TFT LCD connector CN20

A TFT color LCD board is mounted on CN20. Refer to
devices
for details.
All manuals and user guides at all-guides.com
Table 32. MicroSD connector CN16 (continued)
Description

Figure 20. Power supply connector CN17 (Front view)

DocID027916 Rev 2
Pin
Description
number
9
GND
microSDcard_detect
10
(MFX GPIO15)
Figure
20. The central pin of CN17 must be
Section 5.18: Display and input
Connector
45/79
78
