ST User Manual User Manual page 36

Connector
Pin Description
53 PC11
55 PC10
57 PD2
59 GND
2 PI13
4 PC14
6 PC13
8 PK7
10 GND
12 PK5
14 PB9
16 PK3
18 PB6
20 PJ14
22 PJ15
24 PB4
26 PJ13
28 PC12
30 GND
32 PA15
34 PK1
36 PA14
38 PK2
40 PA13
42 PA12
44 PA10
46 PC9
48 +3.3V
50 GND
52 PA8
54 VBUS_FS1
36/79
All manuals and user guides at all-guides.com
Table 22. Daughterboard extension connector CN6 (continued)
Alternative Function
SDCARD_D3 /PAR_D4
SDCARD_D2/EXT_RESET/P
AR_D8
SDCARD_CMD/PAR_D11
-
LCD_VSYNC
OSC32_IN
TAMPER_WAKEUP_KEY
LCD_ENB
-
LCD_B6
I2C1_SDA
LCD_B4
QSPI_BK1_NCS
LCD_B2
LCD_B3
JTRST
LCD_B1
SDCARD_CK/ PAR_D9
-
JTDI
LCD_G6
JTCK-SWCLK
LCD_G7
JTMS-SWDIO
CAN1_TX/USB_FS1_DP/MC
_PFCsync2
RS232_IRDA_RX/USB_FS1
_ID
SDCARD_D1/PAR_D3
-
-
LCD_BL_CTRL/MII_MCO/M
C_PFCsync1
-
DocID027916 Rev 2
How to disconnect with function block on
STM32746G-EVAL board
Remove R275, Disconnect CN4
Remove R16,R281, Disconnect CN4
Open SB63, Disconnect CN4
-
-
Remove R18, Close SB25
Remove R216
Remove R192
-
-
Remove R3, R189,R291, Disconnect CN4
-
Remove R226
-
-
Remove R112
-
Disconnect CN4,CN16
-
Remove R101
-
Remove R93
-
Remove R86
Open SB48,SB49,SB52
Remove R117, Keep JP14 on open
Remove R260, Disconnect CN4
-
-
Open SB56,SB57,SB60
-
UM1902
