Hardware layout and configuration
Pin No.
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
Note: On a 5.7-inch LCD daughterboard, BL_CTRL(PA8) signal adjusts brightness of backlight by
mean of a pulse signal. Since BL_CTRL is shared with MII_MCO, which is in default setting,
SB57 must be removed and SB60 must be closed.
The orientation of the 5.7-inch LCD daughterboard can be changed by hinged standoffs and
pillars. Refer to
26/79
All manuals and user guides at all-guides.com
Table 14. LCD modules connector (CN20) (continued)
Description Pin connection
B0 PJ12
B1 PJ13
B2 PJ14
B3 PJ15
B4 PK3
B5 PK4
B6 PK5
B7 PK6
GND -
INT MFX GPIO14
- -
BL_CTRL PA8
5V -
BLGND -
BLGND -
Figure 5 for details.

Figure 5. Orientation setting of the 5.7-inch LCD daughterboard

,
DocID027916 Rev 2
Pin No. Description
22 ENB
24 -
26 HSYNC
28 VSYNC
30 GND
32 CLK
34 GND
36 RESET#
38 I2C1_SDA
40 I2C1_SCL
42 -
44 -
46 -
48 -
50 3.3V
UM1902
Pin connection
PK7
-
PI12
PI13
-
PI14
-
-
PB9
PB6
-
-
-
-
-
