Connector
6.10

ETM Trace debugging connector CN12

Pin number
1
3
5
7
9
11
13
15
17
19
6.11

USB OTG FS1 Micro-AB connector CN13

Figure 16. USB OTG FS1 Micro-AB connector CN13 (Front view)

42/79
All manuals and user guides at all-guides.com

Figure 15. ETM Trace debugging connector CN12 (Top view)

Table 28. ETM Trace debugging connector CN12

Description
+3.3V
GND
GND
KEY
GND
GND
GND
GND
GND
GND
DocID027916 Rev 2
Pin
Description
number
2 TMS/PA13
4 TCK/PA14
6 TDO/PB3
8 TDI/PA15
10 RESET#
12 TraceCLK/PE2
14 TraceD0/PE3 or SWO/PB3
16 TraceD1/PE4 or nTRST/PB4
18 TraceD2/PE5
20 TraceD3/PE6
UM1902
