RF-EEPROM daughterboard connector CN2
Figure 9. RF-EEPROM daughterboard connector CN2 (Front view)
Pin number
1
2
3
4
6.3
Analog input connector CN3
Pin number
1
All manuals and user guides at all-guides.com
Table 18. RF-EEPROM daughterboard connector CN2
Description
I2C1_SDA (PB9)
NC
I2C1_SCL (PB8)
RESET(PC10)
Figure 10. Analog input-output connector CN3 (Top view)
Table 19. Analog input-output connector CN3
Description
analog input-output (PF10)
DocID027916 Rev 2
Pin number
Description
5
+3V3
6
NC
7
GND
8
NC
Pin
Description
number
2
GND
