MEMS microphone coupon connectors CN24 and CN27
Figure 23. MEMS microphone coupon connectors CN24 and CN27 (Top view)
Table 35. MEMS microphone coupon connectors CN24 and CN27
Pin number
1
2
3
6.22
Audio jack (speaker) CN25
A 3.5 mm stereo audio jack CN25 for speaker out is available on STM32746G-EVAL
evaluation board to support external speaker.
6.23
Audio jack CN26
A 3.5 mm stereo audio jack CN26 is available on STM32746G-EVAL evaluation board to
support headset (headphone and microphone integrated).
All manuals and user guides at all-guides.com
Description
DATA
GND
CLK
DocID027916 Rev 2
Pin number
Description
4
VDD
5
L/R
6
NC
Connector
47/79
