Wakeup Button
+3V3
R218
100
B2
C100 WKUP/TAMPER
[N/A]
R216
PC13
TAMPER_WKUP_KEY
330
R217
220K
+3V3
MICRO SD
(TF) Card
R162 R158 R157 R161 R160
47K 47K 47K 47K 47K
PC9
uSD_D1
PC8
uSD_D0
PC11
uSD_D3
PC10
uSD_D2
PC12
uSD_CLK
PD2
uSD_CMD
CN16
PJS008-2000
SMS064FF or SMS128FF
+3V3
R155
10K[N/A]
R154
MFX_GPIO15
MicroSDCard_Detect
0
To MFX (input with pull up)

Figure 36. STM32746G-EVAL Peripherals

Potentiometer
Potentiometer
Joystick
+3V3
To MFX
JOY_SEL
JOY_DOWN
JOY_LEFT
JOY_RIGHT
JOY_UP
two pin header for external analog input +3V3
CN3
R30
PF10 R28 47 R27 0 2
R29 0
0
3386P-103(10K) RV1
C24
[N/A]
Close to MCU on PCB
+3V3 B3
5
COMMON
7
COMMON
8
COMMON
2
Selection
MFX_GPIO0
MFX_GPIO1 3
DWON
MFX_GPIO2 1
LEFT
MFX_GPIO3 4
RIGHT
MFX_GPIO4 6
UP
EVQQ7
Title: Peripherals
Project:
STM327x6G-EVAL
Size: A4 Reference: MB1167 Revision:
Date: 1/22/2015 Sheet: 12
C90
100nF
9
GND
10
GND
B.1
of 17
