Pin number
1 VBUS (PA9)
2 D- (PA11)
3 D+ (PA12)
6.12

USB OTG FS2 Micro-AB connector CN14

Figure 17. USB OTG FS2 Micro-AB connector CN14 (Front view)

Pin number
1
2
3
6.13

JTAG/SWD connector CN15

All manuals and user guides at all-guides.com

Table 29. USB OTG FS1 Micro-AB connector CN13

Description

Table 30. USB OTG FS2 Micro-AB connector CN14

Description
VBUS (PB13)
D- (PB14)
D+ (PB15)

Figure 18. JTAG/SWD debugging connector CN15 (Top view)

DocID027916 Rev 2
Pin number
4 ID (PA10)
5 GND
- -
Pin number
4 ID (PB12)
5 GND
- -
Connector
Description
Description
