UM1902
Pin Description
56 PC7
58 PC6
60 +5V
6.6

RS232 connector CN7

Pin number
1
2
3
4
5
All manuals and user guides at all-guides.com
Table 22. Daughterboard extension connector CN6 (continued)
Alternative Function
MC_VH/PAR_D1/MIC_CK
MC_UH/PAR_D0/I2S3_CK
-

Figure 12. RS232 connector CN7 (Front view)

Table 23. RS232 connector CN7 with ISP support

Description
NC
RS232_RX (PA10)
RS232_TX (PA9)
NC
GND
DocID027916 Rev 2
How to disconnect with function block on
STM32746G-EVAL board
Disconnect CN1,CN4, Keep JP19 on open
Open SB62, Disconnect CN4, Keep JP4 on
open
-
Pin
number
6 Bootloader_BOOT
7 NC
8 Bootloader_RESET
9 NC
- -
Connector
Description
37/79
