UM1902
6.5

Daughterboard extension connector CN5 and CN6

Two 60-pin male headers CN5 and CN6 can be used to connect with daughterboard or
standard wrapping board to STM32746G-EVAL evaluation board. All GPIOs are dispatched
on memory connectors (CN10 and CN11), and on connectors CN5 and CN6.
The space between CN5 and CN6 connectors is defined as a standard, this allows
developing common daughterboards for several ST evaluation boards. The standard width
between CN5 pin1 and CN6 pin1 is 2700 mils (68.58 mm).
Each pin on CN5 and on CN6 can be used by a daughterboard, after disconnecting it from
the corresponding function block on STM32746G-EVAL evaluation board. Refer to
and Table 22
Pin Description
1 GND
3 PH0
5 RESET#
7 PF6
9 PF10
11 PC0
13 PA2
15 PA0
17 PF8
19 GND
21 PA4
23 PC2
25 PC4
27 PC3
29 PB2
31 PJ3
33 PB10
35 PB14
37 PH6
39 GND
41 PB12
43 PB13
45 PJ9
47 PG7
All manuals and user guides at all-guides.com
for details.

Table 21. Daughterboard extension connector CN5

Alternative Function
-
OSC_IN
-
QSPI_BK1_IO3
LED1/Potentiometer
ULPI_STP
SAI2_SCKB/MII_MDIO/MC_EnIndex Open SB30, Keep JP21 on open
SAI2_SDB/ MII_CRS/MC_ENA
QSPI_BK1_IO0
-
PAR_HSYNC
MII_TXD2/MC_CurrentB
MII_RXD0/
MC_BUSVOLTAGE
MII_TX_CLK/ MC_CurrentC
QSPI_CLK
LCD_R4
ULPI_D3
USB_FS2_DM
MII_RXD2/MC_DissipativeBrake
-
ULPI_D5/ USB_FS2_ID
ULPI_D6/ USB_FS2_VBUS
LCD_G2
MII_MDC_GPIO
DocID027916 Rev 2
How to disconnect with function
block on STM32746G-EVAL board
-
Remove R19, Close SB27
-
Remove R237
Keep JP24 on open
Remove R125
Open SB32,SB34,SB36
Remove R238
-
Disconnect CN4
Open SB38, Remove R241
Open SB40,SB43
Open SB41,SB44
-
-
Remove R102
Remove R288, Disconnect CN14
Open SB42,SB45
-
Open SB51, Remove R109
Remove R115,R259
-
Open SB10
Connector
Table 21
33/79
