Connectors
When an emulator is used with the EZ-KIT Lite, the on-board debug
agent is bypassed.
Expansion Interface II Connectors (P2 and P4)
and are board-to-board connectors providing signals for the SPI,
P2 P4
TWI, UART, SPORT, and GPIO signals of the processor. The connec-
tors are located on the upper edge of the board (one connector is on the
top and one is on the bottom). For more information, see
Interface II" on page
Part Description
50-position 0.1'', SMT header
50-position 0.1'', SMT socket
Expansion Interface II Connector (P3)
is a board-to-board connector providing signals for the PPI and GPIO
P3
signals of the processor. The connector is located on the upper edge of the
board. For more information, see
Part Description
70-position 0.1'', SMT header
70-position 0.1'', SMT socket
2-18
1-15.
Manufacturer
SAMTEC
Mating Connector
SAMTEC
"Expansion Interface II" on page
Manufacturer
SAMTEC
Mating Connector
SAMTEC
ADSP-BF506F EZ-KIT Lite Evaluation System Manual
"Expansion
Part Number
TSSH-125-01-L-DV-A
SSW-125-22-F-D-VS
1-15.
Part Number
TSSH-135-01-L-DV-A
SSW-135-22-F-D-VS
