Table 1-3. Voltage Values

Step Value

Power Measurements

Several locations are provided for measuring the current draw from vari-

ous power planes. Precision 0.1 ohm shunt resistors are available on the

VDDINT, VDDEXT, and VDDFLASH voltage domains. For current

draw, the jumper is removed, voltage across the resistor can be measured

using an oscilloscope, and the value of the resistor can be measured using a

precision multi-meter. Once the voltage and resistance are measured, the

current can be calculated by dividing the voltage by the resistance. For the

highest accuracy, a differential probe should be used for measuring the

voltage across the resistor.

ADSP-BF506F EZ-KIT Lite Evaluation System Manual

Using ADSP-BF506F EZ-KIT Lite

Voltage (V)

1.10

1.15

1.20

1.25

1.30

1.35

1.40

1-17
