Programmable Flags
Table 2-1. Port F Programmable Flag Connections (Cont'd)
Processor Pin Other Processor Function
PF5 RFS0/PWM0_CH/PPI_D10/
TACLK0
PF6 UA1_TX/PWM0_TRIP/
PPI_D12
PF7 UA1_RX/PWM0_SYNC/
PPI_D13/TACI3
PF8 UA1_RTS/DT0SEC/PPI_D7
PF9 UA1_CTS/DR0SEC/PPI_D6/
CZM0
PF10 SPI0_SCK/TMR2/PPI_D5
PF11 SPI0_MISO/PWM0_TRIP/
PPI_D4/TACLK2
PF12 SPI0_MOSI/PWM0_SYNC/
PPI_D3
PF13 SPI0_SEL1/TMR3/PPI_D2/
SPI0_SS
PF14 SPI0_SEL2/PWM0_AH/
PPI_D1
PF15 SPI0_SEL3/PWM0_AL/
PPI_D0
Table 2-2. Port G Programmable Flag Connections
Processor Pin Other Processor Function
PG0 SPI1_SEL3/TMRCLK/
PPI_CLK/ UA1_RX_ALT/
TACI4
PG1 SPI1_SEL2/PPI_FS3/
CAN_RX/ TACI5
2-4 ADSP-BF506F EZ-KIT Lite Evaluation System Manual
EZ-KIT Lite Function
Default: not used
Land grid array, expansion interface II
Default: not used
Land grid array, expansion interface II
Default: not used
Land grid array, expansion interface II
Default: not used
Land grid array, expansion interface II
Default: not used
Land grid array, expansion interface II
Default:
SPI0_SCK
Land grid array, expansion interface II
Default:
SPI0_MISO
Land grid array, expansion interface II
Default:
SPI0_MOSI
Land grid array, expansion interface II
Default:
SPI0_SEL1
Land grid array, expansion interface II
Default: not used
Land grid array, expansion interface II
Default: not used
Land grid array, expansion interface II
EZ-KIT Lite Function
Default:
CAN_ERR
Land grid array, expansion interface II
Default:
CAN_RX
Land grid array, expansion interface II
