VisualDSP++ Install and Session Startup

To disconnect from the target board, click the terminate button
(red box) or choose Run > Terminate.
To delete a session, choose Target > Session > Session List. Select
the session name from the list and click Delete. Click OK.
VisualDSP++ Install and Session Startup
For information about VisualDSP++ and to download the software, go to
www.analog.com/VisualDSP
There are two options to connect the EZ-KIT Lite hardware to a personal
computer (PC) running VisualDSP++: via an Analog Devices emulator or
va a standalone debug module. The standalone debug agent allows a
debug agent to interface to the ADSP-BF506F EZ-KIT Lite. The stand-
alone debug agent is shipped with the kit.
To connect the EZ-KIT Lite to a PC via an emulator:
1. Plug the 5V adaptor into connector
USB cable into
2. Attach the emulator to the header connector
the EZ-KIT Lite.
To connect the EZ-KIT Lite to a PC via the debug agent:
1. Plug one side of the provided USB cable into the USB connector of
the debug agent
into a USB port of the PC running VisualDSP++.
2. Verify that the yellow USB monitor LED on the debug agent,
, is lit. This signifies that the board is communicating prop-
ZLED2
erly with the host PC and ready to run VisualDSP++.
1-8
.
(labeled
ZP1 USB
(labeled
ZP1
ADSP-BF506F EZ-KIT Lite Evaluation System Manual
(labeled
P9
).
P1
). Plug the other side of the cable
USB
) or plug the
5V
(labeled ) on
JTAG
