Table 1-2. EZ-KIT Lite External (Interface-Accessible) Memory Map
Start Address
0xEF00 0000
0x2040 0000
0x2000 0000
0x0000 0000
Internal Flash Memory Interface
Internal parallel flash memory of the ADSP-BF506F EZ-KIT Lite is a
4 MB (2M x 16 bits) Numonyx M58WT032 device, which is internal to
the processor. The address range for flash memory is
.
0x203F FFFF
By default, the EZ-KIT Lite boots from SPI flash memory. The processor
boots from internal parallel flash memory if the boot mode select switch
( ) is set to position 1 or 2; see
SW2
page 2-8.
Flash memory code can be modified. For instructions, refer to the online
help and example program included in the EZ-KIT Lite installation
directory.
SPI Flash Memory Interface
SPI flash memory of the ADSP-BF506F EZ-KIT Lite is a 16 Mb
Numonyx M25P16 device. The device is selected via
SPI flash memory is pre-loaded with boot code for the power-on-self test
(POST) program. For more information, refer to
on page 1-14.
ADSP-BF506F EZ-KIT Lite Evaluation System Manual
Using ADSP-BF506F EZ-KIT Lite
Content
BOOT ROM (4K BYTES)
Reserved
SYNC FLASH (32M BITS)
Reserved
"Boot Mode Select Switch (SW2)" on
to
0x2000 0000
.
SPI0_SEL1
"Power-On-Self Test"
1-13
