Memory Map
Memory Map
The ADSP-BF506F processor has internal static random access memory
(SRAM) used for instruction or data storage. See
memory details can be found in the ADSP-BF50x Blackfin Processor Hard-
ware Reference.
The ADSP-BF506F EZ-KIT Lite board includes external serial peripheral
interconnect (SPI) flash and internal flash memories. See
also the following "Internal Flash Memory Interface" and "SPI Flash
Memory Interface".
Table 1-1. EZ-KIT Lite Internal Memory Map
Start Address
0xFFE0 0000
0xFFC0 0000
0xFFB0 1000
0xFFB0 0000
0xFFA1 4000
0xFFA0 8000
0xFFA0 4000
0xFFA0 0000
0xFF80 8000
0xFF80 4000
0xFF80 0000
0xEF00 1000
1-12
Content
CORE MEMORY MAPPED REGISTERS
SYSTEM MEMORY MAPPED REGISTERS
Reserved
INTERNAL SCRATCHPAD RAM (4K BYTES)
Reserved
Reserved
L1 INSTRUCTION SRAM/CACHE (16K BYTES)
L1 INSTRUCTION BANK A SRAM (16K BYTES)
Reserved
L1 DATA BANK A SRAM/CACHE (16K BYTES)
L1 DATA BANK A SRAM (16K BYTES)
Reserved
ADSP-BF506F EZ-KIT Lite Evaluation System Manual
Table 1-1. The internal
Table 1-2; see
