Table 2-2. Port G Programmable Flag Connections (Cont'd)
Processor Pin Other Processor Function
PG2 SPI1_SEL1/TMR4/CAN_TX/
SPI1_SS
PG3 HWAIT/SPI1_SCK/DT1SEC/
UA1_TX_ALT
PG4 SPI1_MOSI/DR1SEC_ALT/
PWM1_SYNC/TACLK6
PG5 SPI1_MISO/TMR7/
PWM1_TRIP
PG6 PG6 ACM_SGLDIFF/SD_D3/
PWM1_AH
PG7 ACM_RANGE/SD_D2/PWM1_AL
PG8 DR1SEC/SD_D1/PWM1_BH
PG9 DR1PRI/SD_D0/PWM1_BL
PG10 RFS1/SD_CMD/PWM1_CH/
TACI6
PG11 RSCLK1/SD_CLK/PWM1_CL/
TACLK7
PG12 UA0_RX/SD_D4/PPI_D15/
TACI2
PG13 UA0_TX/SD_D5/PPI_D14/
CZM1
PG14 /UA0_RTS/SD_D6/TMR0/
PPI_FS1/CUD1
PG15 /UA0_CTS/SD_D7/TMR1/
PPI_FS2/CDG1
ADSP-BF506F EZ-KIT Lite Evaluation System Manual
ADSP-BF506F EZ-KIT Lite Hardware Reference
EZ-KIT Lite Function
Default:
CAN_TX
Land grid array, expansion interface II
Default: not used
Land grid array, expansion interface II
Default:
SD_WP
Land grid array, expansion interface II
Default:
SD_CD
Land grid array, expansion interface II
Default:
ACM_SGLDIFF
, land grid array, expansion interface II
SD_D3
Default:
ACM_RANGE
, land grid array, expansion interface II
SD_D2
Default:
ADC_DOUTB
, land grid array, expansion interface II
SD_D1
Default:
ADC_DOUTA
, land grid array, expansion interface II
SD_D0
Default:
ADC_CS
, land grid array, expansion interface II
SD_CMD
Default:
ADC_SCLK
, land grid array, expansion interface II
SD_CLK
Default:
UART0_RX
, land grid array, expansion interface II
DS_D4
Default:
UART0_TX
, land grid array, expansion interface II
DS_D5
Default:
UART0_RTS
, land grid array, expansion interface II
DS_D5
Default:
UART0_CTS
, land grid array, expansion interface II
DS_D7
2-5
