GSi GrainVue Installation Manual page 38

Chapter 5: Installing the Power Supply
5. Refer to Figure 8-1, page 51
control wiring with the inclusion of a HOA switch.
6. Place the warning decal as shown in
wiring connected to them.
Figure 5-14 Fan control warning decal
Installing the Plenum and Outdoor Sensor Switch Enclosure
1. Mount the Plenum and Outdoor Sensor Switch Enclosure (37) to the bin wall, using the pre-installed
magnets, at an accessible height from the ground, in a location where the Plenum Sensor Cable can
reach the Fan Control Module.
2. Connect the Plenum Sensor Cable (38) from the Plenum and Outdoor Sensor Switch Enclosure
(37) to the Fan Control Module.
Figure 5-15 Installing the Plenum and Outdoor Sensor Switch Enclosure
37 Plenum and Outdoor Sensor Switch Enclosure
38
in Appendix-A: Fan Control Wiring Diagram, page 51
Figure 5-14, page 38 onto all fans with GrainVue fan control
38 Plenum Sensor Cable
PNEG-2347 Cable Monitoring System
for proper fan
