4
Installing the Cable Monitoring
Hub
1. Remove the wing nuts (26) that are pre-assembled on the Hub (16).
2. Align the Hub (16) with the curved slots in the mounting bracket (17) and re-install using the wing
nuts (26).
Figure 4-1 Assembling the Hub onto the mounting bracket
Cable Monitoring Hub
16
Mounting bracket
17
PNEG-2347 Cable Monitoring System
Wing nuts
26
25
