Summary of Contents for GSi Bulk Feed Tank Series
- Page 1 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series Assembly Manual PNEG-1461 Date: 12-14-12 PNEG-1461...
- Page 2 All information, illustrations, photos and specifications in this manual are based on the latest information available at the time of publication. The right is reserved to make changes at any time without notice. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 3: Table Of Contents
Installation of Leg to Sidewall ......................69 Installation of Leg to Sidewall for 15' BFT ..................70 12'-15' Leg Bracing ..........................71 Bracing Hole Layouts ........................73 Hopper to Leg Bracing ........................76 PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 4 15' Diameter 60° Hopper Bin Hardware Specifications ..............94 15' Diameter 45° Hopper Bin Specifications ..................96 15' Diameter 45° Hopper Bin Hardware Specifications ..............98 Chapter 17 Warranty ............................101 PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 5: Chapter 1 Introduction
Should the equipment be abused, or modified to change its performance beyond the factory specifications, the warranty will become void and field improvements may be denied. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 6: Chapter 2 Safety
CAUTION, used with the safety alert symbol, indicates a CAUTION hazardous situation which, if not avoided, could result in minor or moderate injury. NOTICE is used to address practices not related to NOTICE personal injury. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 7: General Safety Statement
Personnel operating or working around equipment should read this manual. This manual must be delivered with equipment to its owner. Failure to read this manual and its safety instructions is a misuse of the equipment. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 8: Safety Instructions
Keep all parts in good condition and properly installed. Fix Maintain Equipment damage immediately. Replace worn or broken parts. Remove any built-up grease, oil, and debris. and Work Area PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 9 Wear a hard hat to help protect your head. Hard Hat Wear appropriate fall protection equipment when working at elevations greater than six feet (6'). Fall Protection PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 10: Safety Sign-Off Sheet
All unqualified persons are to stay out of the work area at all times. It is strongly recommended that another qualified person who knows the shut down procedure be in the area in the event of an emergency. Date Employee Name Supervisor Name PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 11: Proper Storage Of Grain Bin/Silo Materials Prior To Construction
If “white rust” or “wet storage stain” occurs, contact the manufacturer immediately about ways to minimize the adverse effect upon the galvanized coating. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 12: Chapter 3 Decals
3. Station another person outside the bin. DC-2123 trap and suffocate. collapse and suffocate. kill or dismember. For replacement decals, contact: GSI Decals 1004 E. Illinois St. Assumption, IL. 62510 Phone: 1-217-226-4421 PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 13: Chapter 4 General Information
9. All vertical sidewall sheet seams must be overlapped in the same direction. 10. A hole spacing of 3-1/8" is used at the top of all top sidewall sheets and at the bottom of all bottom sidewall sheets. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 14 4. 1 Large flathead screwdriver 5. 1 Pair of slip joint pliers 6. Two (2) adjustable wrenches 7. Ratchet and sockets 8. Impact wrenches and sockets (if available) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 15: Chapter 5 Foundation
5. Foundation Figure 5A 12' 2-8 Rings BFT/GHT Square Pad PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 16 5. Foundation Figure 5B 12' 2-8 Rings BFT/GHT Round Pad PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 17 5. Foundation Figure 5C 12' 8-10 Rings BFT/GHT Round Pad PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 18 5. Foundation Figure 5D 12' 11 Rings BFT/GHT 16 Leg Round Pad PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 19 5. Foundation Figure 5E 15' 1-6 Rings BFT/GHT Round Pad PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 20 5. Foundation Figure 5F 15' 7-8 Rings BFT/GHT 60° Round Pad PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 21 5. Foundation Figure 5G 15' 7-8 Rings BFT/GHT 45° Hopper Tank PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 22 5. Foundation Figure 5H 15' 9 Rings BFT/GHT 20 Leg 45° Tank PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 23: Chapter 6 Sidewall Assembly
The sheets are color coded, simply match the gauge number with the color. (Use “Sheet Gauge Color Code Chart” on Page 24.) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 24: 12' Sidewall Sheet Orientation
IMPORTANT: Please note sheet orientation when assembling the bin sidewall. The upper right corner will have a slot or identifying sticker. This corner should be on the inside of the tank when assembled. (See Figure 6A.) Figure 6A PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 25: Sidewall Erection
The 12' 45° tanks have an 9 ring maximum.) Figure 6B Ring Overlap Detail Figure 6D Caulking Detail (For 15 Tanks Only) Figure 6C Caulking Detail (For 12 Tanks Only) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 26 When bolting sidewall rings to one another, always begin bolting in the center of the sheet and work toward the outside edges (horizontal seams). This allows the sidewall to draw up evenly. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 27 Now tighten the bolts, in sequence, starting from the center and working to the edge in both directions. This permits the sidewall sheets to draw-up evenly. Complete one ring and stop. You are now ready to assemble the roof. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 28: Chapter 7 Roof
Page 80), the two (2) roof panels with fill hole and exhaust hole must be located opposite each other on Bulk Feed Tank. Figure 7B Eave Detail PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 29: Peak Ring Collar To Roof Panels
Caulking Caulking Peak ring Figure 7C 5/16" x 3/4" Bin bolt Figure 7D Figure 7E Peak Ring Collar Detail PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 30: 12' Roof Reinforcement Angle
7. Roof 12' Roof Reinforcement Angle Figure 7F Figure 7G PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 31: 15' Roof Assembly Instructions
Ensure that all roof seams are caulked and lapped correctly as shown in the accompanying detail drawings. Figure 7H PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 32 7. Roof Figure 7I View “A”-“A” Figure 7K View “C”-“C” Figure 7J View “B”-“B” Figure 7L View “D”-“D” PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 33: Raising The Roof
When the legs are in place and tightened, release the jack enough to rest the tank on the legs. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 34 Figure 7O. Apply caulking between the hopper panel and the sidewall sheet. Figure 7O PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 35: Chapter 8 Optional Bft Ladder Assembly
Figure 8A Ref # Description L.H. Starter Bracket R.H. Starter Bracket Top 4' Ladder Section Connector Bracket Roof Ladder Section Roof Ladder Support Bracket Standoff Bracket Wedge PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 36: Starter Bracket Installation
2.66" below and directly in line with the top row of pre-punched horizontal holes 18-3/4" apart. Refer to Figure 8B for additional clarification of hole locations. Use 5/16" and 3/4" bin bolts for connections. Figure 8B PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 37: Sidewall And Roof Ladder Installation
Failure to follow instructions may cause damage or failure of the equipment. WARNING Roof Ladder Length Bin Diameter 30° Roof 40° Roof Figure 8C PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 38: Roof Ladder Support Bracket Installation
“maximum distances chart” to determine maximum allowable spacing of support brackets. Failure to follow instructions may cause damage or failure of the equipment. WARNING Figure 8D PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 39 8. Optional BFT Ladder Assembly Figure 8E 15' Tank Figure 8F Figure 8G PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 40 8. Optional BFT Ladder Assembly Figure 8H Figure 8I PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 41 Maximum allowable distance between roof ladder 46.5 Inches support brackets. Maximum allowable distance between ladder support 10 Inches bracket and edge of ladder at peak. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 42: Ladder Standoff Installation
8K. Then, slide the standoff assembly along the ladder rail until the standoff is in line with the pre-punched hole in the horizontal seam and attach to the sidewall using 5/16" x 3/4" bin bolts. Figure 8K PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 43: Ladder Section Assembly
8L. Use 5/16" x 3/4" bolts for all connections. NOTE: With most installations, the last ladder section to reach the concrete will need to be cut to fit. Figure 8L PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 44: Ladder Support Detail
8. Optional BFT Ladder Assembly Ladder Support Detail The ladder must be secured to the leg assembly with standoff brackets using support channels as shown Figure Figure 8M PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 45: Chapter 9 Ladder Handrails
(LDR-5414) (2) (LDR-5422) (1) (See Figure 9B on Page 46.) Handrail bar assembly (LDR-5421) (1) (LDR-5414) (2) (LDR-5422) (1) (See Figure 9C on Page 47.) Figure 9A PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 46 9. Ladder Handrails Figure 9B PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 47 9. Ladder Handrails Figure 9C PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 48 9. Ladder Handrails Figure 9D PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 49 9. Ladder Handrails Figure 9E PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 50 9. Ladder Handrails Figure 9F Figure 9G Handrails Fully Assembled PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 51 9. Ladder Handrails Figure 9H PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 52: Chapter 10 Safety Cage
When installed correctly, the bottom of the extension rail should be flush with the bottom of the top ladder section. Use 5/16" x 3/4" bin bolts for all connections. Figure 10A PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 53 Field drill four (4) 5/16" holes through both large and small tubes and bolt together using 1/4"x 1-1/2" bolts and nuts. This will keep the adjustable braces from slipping. (See Figure 10B.) Figure 10B 12' or 15' Diameter PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 54: Safety Cage Hoop Assembly
5/16" x 3/4" bolts with the head of the bolt to the inside of the safety cage. You may now bolt these assemblies to the safety cage brackets. Tighten bolts as you go. Figure 10C PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 55 10. Safety Cage Cage Hoop Bracket Detail Figure 10D Figure 10E PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 56: Safety Cage Installation
Attach cage hoop bracket to ladder. See cage hoop bracket detail on Page Once cage hoop brackets are installed, attach cage hoop halves and tighten bolts. Repeat installation for each safety cage required. Figure 10G PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 57 58. Once the safety cage brackets are installed, attach the bell safety cage hoop half assembly to the safety cage brackets. Tighten bolts as you go. Figure 10H PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 58: Chapter 11 Roof Cap And Ground Control
45° Bulk Feed Tanks. (See Figure 11A.) See Figure 11B on Page See Figure 11F on Page See Figure 11G on Page Figure 11A PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 59 9/16" ratchet, ensuring that the vertical flange tightens past the left edge of the top, horizontal flange, See Figure 11E on Page Mounting brackets Clamp Figure 11C Mount Lid to Peak Ring PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 60 11. Roof Cap and Ground Control Lever arm Mounting brackets Figure 11D Bracket should extend over flange. Figure 11E Tighten Bolts Until Flush with Bracket PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 61 Figure 11F Figure 11G PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 62 4. Install the decal DC-2123 to the inside of peak ring on the hinge side of the lid as shown in Figure 11H. Decal should be clearly visible when lid is open. DC-2123 Figure 11H PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 63 BLK-13028 Spring, R.H. Rear S-7383 Nylock Nut 3/8"-16 ZN Grade 5 S-10121 Bolt, HHCS 7/16"-14 x 9" ZN Grade 5 S-10138 Bolt, FHSCS #10-32 x 3/8" ZN PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 64: Chapter 12 Hopper Assembly
Clean any caulking, which may have squeezed out during assembly, off the inside of the hopper. After the collar is in place, attach the hopper braces and tighten all bolts. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 65 12. Hopper Assembly Figure 12B Stagger Hopper Sheets as Shown Figure 12C 15' 60° Hopper Sheet Detail PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 66 Figure 12F 16" Hopper Collar Detail NOTE: Every hole in hopper sheet will be utilized. Use 5/16" x 3/4" truss head bolt on hopper seams. (Truss head goes on inside of hopper.) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 67: Hopper Collar Assembly
(See Figure 12H and Figure 12I.) Figure 12G Hopper Seam Overlap Detail Figure 12I 16" Hopper Extensions and Collar Figure 12H 22" Hopper Collar PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 68: Chapter 13 Legs And Leg Bracing
13. Legs and Leg Bracing 12' Only Figure 13A Figure 13C Figure 13B PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 69: Installation Of Leg To Sidewall
This provides for a weather-tight seal at the leg attachment location. (See leg size chart on Page 72 before attaching legs.) Figure 13E PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 70: Installation Of Leg To Sidewall For 15' Bft
NOTE: Insert bolts from inside to outside on all leg to tank connections. Figure 13F Plug Holes Figure 13H Installing legs to bin with bolt heads on the inside of bin and nuts on the outside. Figure 13G PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 71: 12'-15' Leg Bracing
Figure 13I below and Figure 13J on Page “B” “A” Figure 13I Typical 12' and 15' 45° Bracing Layout PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 72 Put all legs on, but do not tighten bolts until all braces are in place. Be sure to put leg braces on properly. (See Pages 73-75.) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 73: Bracing Hole Layouts
13. Legs and Leg Bracing Bracing Hole Layouts Figure 13K Figure 13L PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 74 13. Legs and Leg Bracing Bracing Hole Layouts (Continued) Figure 13M Figure 13N All leg to sidewall holes must be utilized for leg attachment. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 75 13. Legs and Leg Bracing Bracing Hole Layouts (Continued) Figure 13O Figure 13P All leg to sidewall holes (22 at 2.666" spacing) must be utilized for leg attachment. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 76: Hopper To Leg Bracing
Cross Tie Brace Usage Chart Description Inside Cross Tie Outside Cross Tie 12' Diameter 45° Hopper 12' Diameter 60° Hopper 15' Diameter 45° Hopper 15' Diameter 60° Hopper PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 77: Chapter 14 Raising Bin
WARNING All usual and customary precautions must be taken to ensure safety of personnel and property. WARNING Standard Hopper Bin Anchoring Figure 14A PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 78: Anchoring Tank
Check all legs to see if shims are necessary to level the tank properly (shims are to be obtained locally). After Bulk Feed Tank is level and shimmed properly, anchor the tank down with 5/8" washers and nuts. (See Figure 14B.) Figure 14B Leg Base Detail PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 79: Bin Grounding Instructions
Figure 14C Ref # Description Cable Clamp 5' (1524 mm) Copper Cable (Plain or Jacketed) Ground Rod Clamp Ground Rod 1/2" x 10' (3048 mm) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 80: Chapter 15 Pneumatic Fill Kit
15. Pneumatic Fill Kit Pneumatic Fill Kit Assembly NOTE: Inlet and exhaust parts from roof eave upward supplied with kit. Figure 15A PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 81: Roof Panel
15. Pneumatic Fill Kit Roof Panel Identical pre-punched roof panels are available from the GSI for inlet and outlet sections of pneumatic fill systems. Extruded lip of the panels provide for weather-tight installation. Caulking placed between angle rings virtually eliminates all leakage problems. Rubber seal must be utilized at roof cap area to prevent material “blow by”... - Page 82 NOTES PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 83: Chapter 16 Parts List
7. 15' Diameter 45° Hopper Bin Specifications - (See Pages 96 and 97.) 8. 15' Diameter 45° Hopper Bin Hardware Specifications - (See Pages 98 and 99.) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... -
Page 84: 12' Diameter 60° Hopper Bin Specifications
IMPORTANT: Bolt heads are inside of bin at the leg to body attachment and on all vertical seams on hopper panels. All bolts to be tightened from the nut side only. Refer to detail on Page 25 for location of caulking. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 85 40° Roof Bulk Tank Peak Ring BLK-12060 12' Inside Cross Tie Brace (67.788") (12 Gauge) BLK-12061 12' Outside Cross Tie Brace (67.788") (12 Gauge) BLK-11840A 12' 60° Hopper Reinforcement Angle (Optional) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 86: 12' Diameter 60° Hopper Bin Hardware Specifications
16. Parts List 12' Diameter 60° Hopper Bin Hardware Specifications Under Collar Clearance 16" Collar 31-3/16" (792 mm) 22" Collar 35-3/4" (908 mm) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 87 Hopper Brace to Leg (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.) S-456 S-7927 Cross Tie Brace to Leg (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.) S-456 PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 88: 12' Diameter 45° Hopper Bin Specifications
IMPORTANT: Bolt heads are inside of bin at the leg to body attachment and on all vertical seams on hopper panels. All bolts to be tightened from the nut side only. Refer to detail on Page 25 for location of caulking. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 89 40° Roof Bulk Tank Peak Ring BLK-12060 12' Inside Cross Tie Brace (67.788") (12 Gauge) BLK-12061 12' Outside Cross Tie Brace (67.788") (12 Gauge) BLK-12021 12' Hopper Reinforcement Angle (Optional) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 90: 12' Diameter 45° Hopper Bin Hardware Specifications
IMPORTANT: Bolt heads are inside of bin at the leg to body attachment and on all vertical seams on hopper panels. All bolts to be tightened from the nut side only. Refer to detail on Page 25 for location of caulking. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 91 Hopper Brace to Leg (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.) S-456 S-7927 Cross Tie Brace (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.) S-456 PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 92: 15' Diameter 60° Hopper Bin Specifications
IMPORTANT: Bolt heads are inside of bin at the leg to body attachment and on all vertical seams on hopper panels. All bolts to be tightened from the nut side only. Refer to detail on Page 25 for location of caulking. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 93 22" 60° Hopper Collar (36 Holes) BLK-11730 Bulk Tank Peak Ring BLK-12062 15' Inside Cross Tie Brace (64.4") (12 Gauge) BLK-12063 15' Outside Cross Tie Brace (64.4") (12 Gauge) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 94: 15' Diameter 60° Hopper Bin Hardware Specifications
IMPORTANT: Bolt heads are inside of bin at the leg to body attachment and on all vertical seams on hopper panels. All bolts to be tightened from the nut side only. Refer to detail on Page 25 for location of caulking. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 95 Hopper Brace to Leg (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.) S-456 S-7927 Cross Tie Brace to Leg (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.) S-456 PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 96: 15' Diameter 45° Hopper Bin Specifications
IMPORTANT: Bolt heads are inside of bin at the leg to body attachment and on all vertical seams on hopper panels. All bolts to be tightened from the nut side only. Refer to detail on Page 25 for location of caulking. PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 97 22" 45° Hopper Collar (36 Holes) BLK-11730 Bulk Tank Peak Ring BLK-12062 15' Inside Cross Tie Brace (64.4") (12 Gauge) BLK-12063 15' Outside Cross Tie Brace (64.4") (12 Gauge) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 98: 15' Diameter 45° Hopper Bin Hardware Specifications
16. Parts List 15' Diameter 45° Hopper Bin Hardware Specifications Under Collar Clearance 16" Collar 34-1/16" (865 mm) 22" Collar 36-5/8" (930 mm) PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series... - Page 99 Hopper Brace to Leg (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.) S-456 S-7927 Cross Tie Brace to Leg (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.) S-456 PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
- Page 100 NOTES PNEG-1461 12' and 15' Bulk Feed Tank Series and Grain Hopper Tank Series...
-
Page 101: Chapter 17 Warranty
14 months from arrival at port of discharge, whichever is earlier. The end-user’s sole remedy (and GSI’s only obligation) is to repair or replace, at GSI’s option and expense, products that in GSI’s judgment, contain a material defect in materials or workmanship. - Page 102 Authorities having jurisdiction should be consulted before installations are made. GSI Group 1004 E. Illinois St. Assumption, IL 62510-0020 Phone: 1-217-226-4421 Fax: 1-217-226-4420 www.gsiag.com Copyright © 2012 by GSI Group Printed in the USA CN-208661...
